Manufacture EMC LED Intellignt PWM Led Driver Dimmable

Name: Manufacture EMC LED Intellignt PWM Led Driver Dimmable
Brand: Huagao
SKU: 134615987
Availability: InStock

US$ 6 - 12 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Huagao

Model Number:

HG-OPW-WI40-920

Shenzhen Huagao Optoelectronics Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Huagao

Model Number HG-OPW-WI40-920

Output Power Other, 30-40W

Output Type Single

Input Voltage Other, AC90V-264V

Output Voltage DC30-40V

Output Frequency 47-63Hz

Output Current 560-900mA

Specifications

led driver dimmable
1.Control distance 20-30m
2.Size;150*42*32mm
3.Power factor:0.95
4:Certificate:CE,EMC

LED Intellignt Power Series(PWM dimming driver)

led driver dimmable

Description

1:Constant current output

2.Built-in active PFC function.

3.Can be controlled in the distance 20m - 30m

4.High efficiency,low power consumption led light driver

5:Conversion efficiency:>90%

6:Power factor (PF):>0.95

7.Protecting features of short circuit / open circuit / over-heat / overload,

8.Fully isolated plastic case

9.Quick assembly and easy installation led light driver

10.Approved by CE RoHS VDE TUV

Specification

Model	HG-OPW-WI40-920	HG-OPW-WI40-960
Output power	30-40W	50-60w
Output voltage	DC30-40V	DC30-42V
Series connection	10-12series	10-12series
Output current	560-900mA	920-1250mA
Input Voltage	AC90-264V	AC90-264V
Frequency	47-63HZ	47-63HZ
Conversion efficiency	88%	89%
Power factor	0.95	0.93
Size	1504232mm	1407135mm
Application	Apply to led lighting
Protection	Over-heat,over-load,short-ciruit,open-circuit protection
Certificate	Approve by VDE,TUV,ETL,FCC,CE,EMC
