Home > Products > LED Power Driver > CE EMC manufacture LED intellignt PWM 560mA dimmable led driver
CE EMC manufacture LED intellignt PWM 560mA dimmable led driver
- 5000 Piece / Pieces per Month
- Shenzhen
- Credit Card
- ME Series Modules High Stability High Voltage Power Supply for Microchannel Plates
- MMC Series DC High Stability Voltage Power Supply for Microchannel Plates (100V-600V,0.1W)
- Brand new power box 640C0022G01 York control system motherboard power supply GLC75D-CVG
- Power Supplies TVD1.3-15-03 Original Stock
- 10W 2.5KV Isolation Wide Input AC/DC Converters
- 30W Wide Voltage Input DC/DC Converters power supply
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Huagao | Model Number: | HG-OPW-WI40-920 |
Output Power: | Other, 30-40W | Output Type: | Single | Input Voltage: | Other, AC90V-264V |
Output Voltage: | DC30-40V | Output Frequency: | 47-63Hz | Output Current: | 560-900mA |
Product Description
Specifications
560mA dimmable led driver1.Control distance 20-30m
2.Size;150*42*32mm
3.Power factor:0.95
4:Certificate:CE,EMC
LED Intellignt Power Series(PWM dimming driver)
560mA led dimmable driver
Description
1:Constant current output
2.Built-in active PFC function.
3.Can be controlled by dimmer or phone in the distance 20m - 30m
4.High efficiency,low power consumption led light driver
5:Conversion efficiency:>90%
6:Power factor (PF):>0.95
7.Protecting features of short circuit / open circuit / over-heat / overload,
8.Fully isolated plastic case
9.Quick assembly and easy installation led light driver
10.Approved by CE RoHS VDE TUV
Specification
Model | HG-OPW-WI40-920 | HG-OPW-WI40-960 |
Output power | 30-40W | 50-60w |
Output voltage | DC30-40V | DC30-42V |
Series connection | 10-12series | 10-12series |
Output current | 560-900mA | 920-1250mA |
Input Voltage | AC90-264V | AC90-264V |
Frequency | 47-63HZ | 47-63HZ |
Conversion efficiency | 88% | 89% |
Power factor | 0.95 | 0.93 |
Size | 150*42*32mm | 140*71*35mm |
Application | Apply to led lighting | |
Protection | Over-heat,over-load,short-ciruit,open-circuit protection | |
Certificate | Approve by VDE,TUV,ETL,FCC,CE,EMC |
Product presention
560mA led dimmable driver
Our certificate
Our Factory
Contact Us
- Shenzhen Huagao Optoelectronics Technology Co., Ltd.
- Contact nameella Yang
- Phone86-755-84501181
- Address3F/Blk C, Xinmusheng Low-Carbon Industry Park, No.6 Xinmu Avenue, Pinghu, Longgang, Shenzhen, China Shenzhen,Guangdong
