Home > Packaging & Printing > Packing Machinery > Filling Machine > Wine Filling Capping Machine

Wine Filling Capping Machine

US$ 10,000 - 100,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Jiangsu, China

Brand Name:

Model Number:

CGF

Contact Supplier Request Quote Chat Now

Zhangjiagang Huanyu Beverage Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Jiangsu, China

Brand Name HY

Model Number CGF

Specifications

Beer washing/filling/capping machine monoblock
1. Speed:2000-10000bph
2. Material: SuS304
3.Feed bottle by screw

Beer washing/filling/capping machine monoblock

Beer filling machine

Our glass bottle beer filling machine use bottle base handling method and bottles are lifted at filling position. for different bottle sizes, height adjustment is required for different machine units and change over parts need to be replaced. conveyor height adjustment is not required. Isao baric filling is used and gas containing liquid can be filled. filling level is stable. spring type rinsing clamp is used. empty bottle overturns by 180 degree; automatically along guide track to rinse bottle inside.

plum blossom shaped rinsing nozzle is used to give high rinsing efficiency by rinsing bottle bottom from different angles. filled bottles are sealed with crown corks to ensure airtight sealing. crown corks are sorted by inclined centrifugal sorter that will not damage cork surface. cap hopper will signal the cap conveyor to feed caps automatically in case of cap absence. the machine is capable of recirculation cip cleaning. other functions include waiting in case of bottle absence, automatic stop in case of cap absence in cap chute, etc.

this machine is fabricated according to corresponding safety rules. the machine structure enables its non-hazardous operation in time of regulation, service, maintenance, repair and troubleshooting. during performing of such job, the machine ought to be turned by hand or using jog switch.
in case those safety devices shall be deactivated during maintenance and repair, this must be done by trained and authorized persons. check that there is no tools or rags in the bottle channel and all moving parts are not obstructed every time before switching on power.

it is very important to read all safety rules and instructions to dedicated safety personnel carefully.

Product Feature

Advanced programmable PLC is equipped to control the main machine. Main electronic components are all from famous international enterprises.

All spare parts that may touch with water are made from high-quality stainless steel.

Product Specification / Models

Type	BCGF16/12/6	DGF18/6	DGF24/6	DGF32/8
Product capacity (500ml b/h)	2000	4000	6000	8000
Total Power (KW)	1.5	1.5	2.2	2.2
Dimension (mm)	1700x1100x2300	1830x1320x2300	1950x1580x2500	2100x1850x2500
Total weight (kg)	2000	2400	3000	3500

Model:	BCGF16/12/6	BCGF16/16/6	BCGF18/18/6	B CGF24/24/8	BCGF32/32/10
Production(500/m/bottle/h):	3000	5000	8000	10000	12000-14000
washing filling and capping heads	16 12 6	16 16 6	18 18 6	24 24 8
Bottle size	Circular or square bottleBottle diameter(mm): Φ50-φ90 Bottle height(mm): 150-310
Compressed air pressure(MPa):	0.3-0.7
Washing medium:	Aseptic water Washing
waters pressure(MPa):	0.25
Total output (KW):	3.13	3.84	3.84	4.1	5.6
Oerall dimensions(mm):	2500x1500x2500	2500x1800x2500	3200x2200x2800	3400x2600x2800	3600x2800x3000
Weight (kg):	2500	3000	3500	4500	5000
