Sleeve Shrink Labeling MachineIt's designed for wrap around labels
Large capacity and widely used
Easily control,change..
Sleeve Shrink Labeling Machine
This machine demands the label is sticky label.
Super Heavy-duty in Mechanical Structure:
T6 aluminum alloy and stainless steel material are adopted on the machinery body, it looks blazonry and munificent tout ensemble. No belt is visible exteriorly, thus the security is very high. 85% of the machinery parts are self-manufactured within our factory, therefore, we can have an effective quality control and are able to cut down the production cost.
Easy to operate, handy and fast:
In the occasion of changing specification, the adjustment is simple and fast! In the event that the radii of the bottles are within the range of 25 to155, it shall not be necessary to adjust the cutter knifes, thus the time for changing lines is saved. The Mitsubishi PLC and servo-drive are adopted, and the man-machine interface setting and adjusting are also put in use effectively which makes the operating even easier.
Having patents on many designed items:
The rotate device used in the heat shrinking to settle the problems on the uneven heating of labels and on the ill-shrinkage thereof. This device is especially suitable to be used in the compact disc pudding tubes and irregular bottles.
The cutting device on the unique knife tray no need for belt drive, the actions of exchange or maintenance become fast and accurate, and the cutting edges even and tidy. The Japanese made industrial art blades are used on the cutter knives which enable the machine to lengthen its service life.
Patent designed label drive mechanism only one pivot button is to be adjusted to move four driving support trindles synchronously, therefore, it is very easy to replace the center guiding pillar.
Machine features:
1. Diameter of bottle is Ø25~155mm, max bottle could design for especially.
2. Peculiarity rid adjust knife set, in the range of specification rid adjust razor blade, save time for change production line. There are four specifications of knife set can be choose:
a.Ø25~60m/m b.Ø50~98m/m
c.Ø90~125m/m d.Ø115~155m/m
3. Share design for cylinder & multi-angle bottle.
