Specifications
DY-HPTP thermoplastic pedestrian road marking machine used for marking pedestrian or zebar line by pull the machine.DY-HPTP Thermoplastic Pedestrian Road Marking Machine
Description of DY-HPTP Road Marking Machine
DY-HPTP thermoplastic pedestrian road marking machine used for marking pedestrian or zebar line by pull the machine.
Main Feature of DY-HPTP Road Marking Machine
1. The mrking line is more straight and neat.
2. Precision steel wheel spider and hegh speed bearing, makes machine moving lightly and flexibly
3. Individual design of the handle bar conforms to the requirements of human body project.
Technical Parameter of DY-HPTP Road Marking Machine
No. |
Item |
Spec. |
1 |
Marking Shoe |
Integrative marking shoe and paint tank. Double-closed screeding structure,Heating, abrasion and oxidation resistance |
2 |
Paint Tank |
30L. With sieve in it, effectively removes impurity in paint |
3 |
Heating System |
Petroleum liquefied gas tank supplies gas to the frontal, back nozzle and igniter, the power is controlled by different valves respectively |
4 |
Glass Beads Bin |
11L, With a window, The automatic quantitative dispenser synchronous with the paint screeding system |
5 |
Size and Weight |
1000*720*860mm 140kg |
