Zhengzhou Dayu 60-150m3/h Concrete Batch Plant for Sale

Zhengzhou Dayu 60-150m3/h Concrete Batch Plant for Sale thumbnail-1
Zhengzhou Dayu 60-150m3/h Concrete Batch Plant for Sale photo-1
US$ 60,000 - 600,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Power Type:
Electric
Place of Origin:
Henan, China
Contact Supplier Request Quote Chat Now
Zhengzhou Dayu Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
The main port of China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Power Type Electric
Place of Origin Henan, China
Brand Name Dayu
Model Number 60m3-150m3/h
Power(W) 105kw-260kw
Certification CE,GOST,ISO
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Zhengzhou Dayu concrete batch plant for sale
ISO,CE,GOST
Train your staff
12 months warranty
22 years production experience

Zhengzhou Dayu 60m3-150m3/h concrete batch plant for sale





Zhengzhou Dayu 60-150m3/h concrete batch plant for sale

About us:

As top10 concrete batch plant manufacturer of China,Zhengzhou Dayu Machinery Co.,Ltd. established in 1992 and has been engaged in concrete batch plant producing for 22 years.

Dayu company business scope:

Stationary Asphalt Mixer Plant:

LB series:40t/h--400t/h.(Batch Mix Type)         DHB series:20t/h--100t/h.(Drum Mix Type)

Mobile Asphalt Mixer Plant:

MDHB series:20t/h--100t/h.(Drum Mix Type)        SLB series:8t/h--30t/h.(Drum Mix Type)

QLB series:10t/h--80t/h.(Batch Mix Type)

Concrete Batch Plant:

Stationary concrete batch plant:HZS series from 25m3/h--150m3/h.

Mobile concrete batch plant:YHZS series from 40m3/h--80m3/h.

 Zhengzhou Dayu 60-150m3/h concrete batch plant for sale   Zhengzhou Dayu 60-150m3/h concrete batch plant for sale   Zhengzhou Dayu 60-150m3/h concrete batch plant for sale   Zhengzhou Dayu 60-150m3/h concrete batch plant for sale

Zhengzhou Dayu 60-150m3/h concrete batch plant for sale

Product Introduction of Belt Conveyor Concrete Batch Plant For Sale

The belt conveyor concrete batch plant is the optimal equipment of large and medium construction sites ,water power,highway,harbor,bridge,airport,large precast products plant and comercial concrete plants and so on.

Main Features of Belt Conveyor Concrete Batch Plant For Sale

1.The driving system of  the belt conveyor concrete batch  plant on sale adopts planetary gear, the gimbals transmission shaft insures circumgyrate at the same speed.
2. Mixing system choose the spiral mixing system , which has high efficiency , scale board and mixing blades adopts high-rigidity and high tenacity wearable case alloy steel, to prolong the working life.
3. Aggregate lifting appliance adopts frequency control, thus providing smooth and reliable operation.
4. Lubrication system adopts advanced centralized oil lubricating system, convenient for oil supplying, this system is equipped with overvoltage warning and low oil level warning, safe and reliable.
5. PC+PLC control system ensures the high reliability.

Technical Parameters of Belt Conveyor Concrete Batch Plant For Sale

Entire Plant

Type

HZS60

HZS90

HZS120

HZS150

Capacity (m3/h)

60

90

120

150

Standard Discharging Height(mm)

3800

3800

4000

4000

Operation Cycle Time(s)

60

60

60

60

Max Aggregate Size(mm)

60/80

60/80

60/80

60/80

Total Installed Power(kw)

105

145

210

260

Total Weight (T)

50

60

80

100

Size(m)
(L x W x H)

28.5x10.6x18.8

58.6x12.4x18.8

60.2x13.7x18.8

43.6x24.0x18.8

Mixing System

Mixer

JS1000

JS1500

JS2000

JS3000

Mixing Motor(kw)

2x18.5

2x30

2x37

2x55

Batching System

Batching Machine

PLD1600

PLD2400

PLD3200

PLD4800

Capacity of Storage Hopper(m3)

4x5

4x10

4x18

4x25

Weight System

Aggregate Weighing Precision(%

±2

±2

±2

±2

Cement Weighing Precision(%)

±1

±1

±1

±1

Water Weighing Precision(%)

±1

±1

±1

±1

Additive weighing Precision(%)

±1

±1

±1

±1

Screw conveyor

Zhengzhou Dayu 60-150m3/h concrete batch plant for sale

Batching machine

Zhengzhou Dayu 60-150m3/h concrete batch plant for sale

Working site

Zhengzhou Dayu 60-150m3/h concrete batch plant for sale

Customer visit picture

Zhengzhou Dayu 60-150m3/h concrete batch plant for sale

Our certificates

Our service including:
1.12 months warranty;
2.Erecting the plant;
3.Commissioning the plant;
4.Training the operator;
5.Providing of spare parts;
6.whole life’s technical consultant of the plant.



Rose Jia/Export Dept.

Zhengzhou Dayu 60-150m3/h concrete batch plant for sale

Zhengzhou Dayu Machinery Co.,Ltd.

Mobile: +86-13673658622

Tel: +86-371-55635088    Fax: +86-371-55635099

E-mail: rose@dayucn.biz   Skype: dayu.rose

Web:     www.dayu-concrete.com

Add: No.18 Dongfeng Road,Zhengzhou,Henan,China
