Specifications
Flame Adjustable Burner1. Five wind tunnel
2. For 25-320t/h asphalt plant
3. Compact flame shape
4. energy saving
the coal burner of asphalt plant, 2014 best price of pulverized coal burner
General parameters------ Pulverized Coal Burner:
Model |
RM500 |
RM1000 |
RM1500 |
RM2000 |
RM3000 |
RM4000 |
Power |
31.25 kw |
41.25 kw |
73.75 kw |
97.25 kw |
138.45 kw |
202.95 kw |
Rated coal consumption |
450 kg/h |
1000 kg/h |
1500 kg/h |
2000 kg/h |
2860 kg/h |
3660 kg/h |
Mixture temperature control |
130-180°C |
130-180°C |
130-180°C |
130-180°C |
130-180°C |
130-180°C |
Main machine |
LTZ40 |
LTZ80 |
LTZ120 |
LTZ160 |
LTZ240 |
LTZ320 |
Coal crusher |
FMJ40 |
FMJ80 |
FMJ120 |
FMJ120+ FMJ40 |
2*FMJ120 |
3*FMJ120 |
Oil burning igniter |
RYDH |
RYDH |
RYDH |
RYDH |
RYDH |
RYDH |
Distribution cabinet |
PD40 |
PD80 |
PD120 |
PD160 |
PD240 |
PD320 |
Combustion completeness |
≥95% |
≥95% |
≥95% |
≥95% |
≥95% |
≥95% |
Matching asphalt plant output |
25-40 t/h |
70-85 t/h |
100-125 t/h |
140-170 t/h |
200-250 t/h |
280-320 t/h |
Features------ Pulverized Coal Burner :
1. Adopt innovative design structure, no visible stack emissions
2. High flame temperature, compact flame shape, energy saving;
3. Adopt high performance refractory brick, prolong service life;
4. 24 hours continuous production, no need do slag removal work everyday;
5. Low production cost, which is only about 1/5 of the oil burner .
6. Coal Burner suppliers for other Chinese famous brand boilers and asphalt plant.
Introduction:
RM Pulverized Coal Burner with a specially designed multi-stage air-driven structure to speak out of turn, can produce in a short time so that high-temperature pulverized coal swirl with burning completely, heat utilization high, smoke dust, efficient energy saving, improvement of working conditions, reducing labor intensity, etc.,RM pulverized coal burners are ideal for energy saving and environmental protection products.
Requirements of fuel
1. Use 0 # diesel for oil burning igniter
2. Requirements for the quality of coal using for burning:
1) Mark of coal: bituminous coal
2) Calorific value: ≥25kJ
- gross calorific value 7000 kcal/kg
- net calorific value 5000 kcal/kg
3) Yield of volatile matter: ≥25%
4) Permissible ash 8~10%
5) Total moisture 3~4%
6) Total sulphur ≤1%
7) Particle size: ≤20mm
Note: These indexes are the lowest requirements for the coal, the better coal will be better at practice.
3. Environment friendly:
Combustion completeness ≥95%,
Air black: Ringelmann 0-I grade, no harm to environment
Our service including:
18 months warranty; Erecting the plant; Commissioning the plant; Training the operator; Providing of spare parts; whole life’s technical consultant of the plant.
Over Sea Offices
1. Office in Philippines:
Add: 104 c3 Road Corner 6th street, Caloocan city, Philippines.
2. Office in Algeria:
Add: 09-Bekhti miloud Remchi, Tlemcen13300 Algeria.
3. Office in Sri lankan:
Add: 507/a/07, Maharagama Road, Hokandara, Nr. Sri lanka.
(More information please contact us freely.)
Contact: Asie Liu/Export Dept.
Zhengzhou Dayu Machinery Co.,Ltd.
Mobile: +86-13676994224
Tel: +86-371-55635088 Fax: +86-371-55635099
E-mail: asie@dayucn.biz Skype: dayu.asie
Web:
Add: No.18 Dongfeng Road,Zhengzhou,Henan,China
