Mobile Light Tower Powered by KUBOTA DIESEL ENGINE

FOB Price

US$ 1 - 100,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Model Number	RPLT6800
Place of Origin	Fujian, China		Brand Name	Robust Power

Mobile Light Tower powered by Kubota engine;
358 degree non-continuous;
Mechanical, electric or hydraulic mast are optional;

Model RPLT6800
Technical Specifications
Mast
Maximum extention of mast	8m
Elevation	Hydraulic
Raising/lowing mast	Button(Hydraulic)
Stages	6
Turning angle	358 degrees non-continuous
Lamp
Total power of lamps	4×1000W
Type of lamp	Metal halide lamp
Light capacity	4×110,000 lumen
Voltage	230V
Frequency	50Hz
Lifetime of lamp	5,000hours
Working temperature	≤85°C
Connection Protection index	IP54
Characteristics of the generator
Model	RD-10K
Generator set Prime power	50Hz 6.7kW / 60Hz 8.4kW
Engine model	Japan KUBOTA D1105-BG / UK PERKINS 403D-11G
Intake system	Natural Aspiration
Engine type	Vertical 4-cylinder,liquid cooled Diesel
No.of cylinders	3
Standby power for 50HZ(1500rpm)	9.5KW/50HZ; 11.5KW/60HZ
Alternator	STAMFORD PI 044F
Alternator Type	Brushless,self-excitation
Voltage regulation	Automatic
Alternator Prime power(pf:0.8)	6.7KW/50Hz 8.4KW/60Hz
Voltage	230V
Frequency	50HZ / 50HZ
Fuel tank capacity	100L
Prime fuel consumption at 100% load	2.0L/h
Working hours	50hours
Trailer
Road trailer with hitch ball
Packing Dimension & Weight
Storage	2650mm × 1300mm × 2450mm
Working	2650mm ×2400mm ×8000mm
