Specifications
vertical packaging machine1. package type: bag
2. application: juice, milk, wine, hair pack,skincare item,sauce etc.
Products details
Technical Information
| Type | Liquid packing machine |
| Voltage | AC220V |
| Power | 2KW |
| Size of paper | 320mm |
| Dimension Packing bag | 40-150mm(W), 50-200mm(L) |
| Packing speed | 10-70 bags/min |
| Weight | 300Kg |
| Dimension | 860L*700W*1820H(mm) |
Products Details
Introduction & Advantage
1. Language indication. it can be custom-made. just tell us the language you want.
2. Siemens touch display, can show indicate working status, operation instruction etc. very clear.
3. Simens PLC provide the stable working system.
4. preset formula of 10 products. can change the package of products easliy.
5. Intelligent temperature controller, the difference in temperature is within 2 degree.
6. can adjust the loaction of seal. no need to turn off the machine.
7. Pattern of tooth sealing, packing is very firm, then, straight burr, twill, overlapping curve etc.
8. Protection grade is IP65
9. support many types of bag. such as, flat bag(back seal, trangle seal, four side seal), accordion pocket, hand bag, die-cut bag etc.
10. can design all kinds of punching
11. our packing machine, also provide pressure device, which can make the packing bag more solid.
12. Also have the new designed device for too heavy products and soft products.
13. if the paper you use is single layer PE material, we can equip special PE paper sealed device.
GONGYI DYAN MACHINERY FACTORY is the professional manufacturer specialized on Food processing machine and Farm machinery. Products have been exported to over 10 countries all over the world.
