Nutshell Wood Powder Machine
Standard wood powder machine structure and principle of crushing:
1. Crushing blade: type of knife.
2. Attached to the machine by the drum screen, bin, dust catcher, part of the pipeline.
3. Driven by a motor crusher rotor high-speed operation, make the machine produces high-speed airflow to crush materials to produce high strength impact force, compression force, cutting force, friction force, to achieve unique crushing function.
Standard wood powder machine fineness regulation method:
1. Fineness: 30-325 mesh adjusted, yield and fineness of different differ according to the proportion of the material. Host motor but can small, according to production material fineness.
2. Machine with drum screen, can replace the screen mesh size to adjust the fineness of finished product requirements, product qualification rate reached 100%.
Standard wood powder machine parameters:
| Model | WP-500 | WP-700 | WP-800 | WP-900 | WP-1000 |
| Motor power(kw) | 22 | 37 | 45 | 45-55 | 55 |
| Drum screen motor(kw) | 3 | 4 | 4 | 4 | 4 |
| The host RPM(r/min) | 2970 | 2970 | 2970 | 2970 | 2970 |
| Output(kg/h) | 60-600 | 60-700 | 80-800 | 100-900 | 100-1000 |
| Final product size(mesh) | <=325 | <=325 | <=325 | <=325 | <=325 |
| Overall size(m) | 4.5*2*5 | 4.5*2.5*5 | 5*2.5*5 | 5*2.5*5 | 5*2.5*5 |
