Rice Straw Crushing Machine High Quality High Capacity Perfect Output

Specifications

Wood Chipping Machine:
1. Easy to operate
2. High Production
3. Low energy cost
4. Long durablity

Briquette Crushing Machine prepare suitable size raw material for biomass briquetting plant. According to different raw material, users should use suitable crushers. Hammer mill is to crush small sized material with diameter no more than 50mm. Such like tree branck, tree trimmings, wood chips, wood cuttings, cotton stalk, corn stalk, wheat straw etc. Plate type crusher is to crush tree logs with diameter less than 200mm to 3-5mm at any length.

Briquette Crushing Machine Series:


1. FSJ-1 Crusher: This model of crusher is suitable for crushing raw wood with size less than 200mm(diameter). After milled, the output size can reach diameter 3-5mm , which is suitable for further briquetting.



2. FSJ-2 Hammer mill: This model of Hammer Mill is suitable for milling raw material like tree branch, cotton stalk, corn stalk, wheat straw etc) with size less than 50mm(diameter). After milled, the output size can reach diameter 3-5mm , which is suitable for further briquetting.

Advantages of Briquette Crushing Machine:



1. To ensure security, the feed inlet of this machine adopts self-suction design to avoid serious damage to operators.
2. Low investment and energy consumption
3. High output
4. High-quality finished products
5. Easy to operate and miantain

Technical Data:



Model	Capacity	Power	Weight	Dimention
FSJ-1	300-400kg/h	15kw	375kg	1.3mx0.9mx1.0m
FSJ-2	700-900kg/h	18.5kw	560kg	1.66mx1.2mx1.77m
