HDMI 19P Female Smt DIP Gold-plated Connector

FOB Price

Negotiable / Piece

2000 Pieces(Min. Order)

Port Shenzhen
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	XF
Model Number	HDMI 19P female DIP	Gender	Other, female
Type	Other, HDMI

Product Description

Specifications

1. ISO9001 and ROHS certified
2. Fast the data transmiting speed
3. Customization available
4. Short lead time

HDMI 19P female smt DIP gold-plated connector

Quick Details

Place of Origin: Guangdong China (Mainland)	Brand Name: XF	Model Number: hdmi 19p connector
Type: HDMI	MOQ: 2000	Gender: Female
Function: SMT	Pin Number: 19 pin	Plated: gold
Fabrication Process: stamping	Type: terminal with rubber core	Shell: Thermoplastic ,UL 94V-0

Package &Delivery

Packaging Detail:

1.50 pieces in a plastic pipe and 50 pipes in a carton.

2.1500 pieces in a roll of tube

Delivery Detail:

7 days after payment

Specification

Working Temperature	-40°C ~+70°C
Rated Load	DC 48V 0.2A
Contact resistance	≤50mΩ
Insulation resistance	≥100MΩ
Withstand voltage	AC 500V (50Hz)/min
Insertion and extraction force	5~30N
Electrical Life	5,000 cycles Min
Mechanical Life	10,000 cycles Min
Applications
Our products are suitable for varies types of mobile phone, computer, digital camera, data line, U disk and so on.

Features

1. A Type/B Type/Mini Type ect.kinds of connector design

2. Flexibility design for terminal interface to ensure nice contact and prolong the operating force

3. The place that the terminal contacting is gold-plated, it is to fast the data transmitting speed

4. The place that terminal soldering is nickel-plated, it is to make the soldering better

How to get price for this HDMI 19P DIP?

1. E-mail us with the type you are interested in.

2. We will reply to you with price in one working day.

Ordering Notes

1. You can order single items as sample

2.Shipping worldwide.
