Solar water hater project for 10tons hotel hot water details:
Model: FD-NPC58-11500L
Solar water heater project features
1. Temperature conservation layer in chest
2. Economical and practical
3. Environmental conservation and energy saving
4. According to the required configuration, it can be divided into two types, one is vertical and the other is horizontal
Solar water heater project applications
1. Hotels, resorts, hospitals and hostels
2. Process industry, boiler feed, laundry and canteens
3. Agricultural sector, hatcheries and dairies
4. Process industry, Boiler feed, Laundry and canteens
5. Agricultural sector, hatcheries, and dairies
6. Swimming pool heating
7. In-process heating
8. Health clubs (Steam / Sauna)
Non-pressure solar collector material specification
Descripition | Solar water heater project |
Material of out manifold | 0.4mm thickness color steel/ fluorine carbon steel |
Material of inner tank | Food grade 0.4mm thickness SUS304 stainless steel |
Tank insulating layer | 40mm 45kg/m³ high-density polyurethane foamed |
Inlet and outlet hole | Male G3/4 |
Max pressure | 0.05 Mpa |
Solar collector tube | 3.3 Borosilicate glass with N/Al coating |
Thickness of glass tube | 1.6mm |
Vacuum tube tightness | P≤0.005 Pa |
Absorption | as=0.93-0.96(AM1.5) |
Emission ratio | εh=0.04-0.06(80C±5C) |
Idle sunning property parameters | Y=220~260m2.C/KW |
Average heat loss coefficient | ULT=0.6~0.7W/(m2.C) |
Bracket: | 1.5mm thickness Galvanized Steel |
Welding: | Argon arc welding |
Project size | 1pcs x 2000L solar project |
Absorber area | 18.74m² |
Tube quantity | 200tubes (10pcs 58x1,800mmx20 tube collector) |
Solar water heater project details:
The sponsor: The World Bank
Supplier: Fadi Solar
Location: Moscow,Russia
Collector:10pcs x 20tube solar collector
.1pcs x 2000L storage tank
