Hot Sale!!! The New Product- 8 Ports Alarm display stand security for mobile phone/carema/tablet PC

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 4000 Piece / Pieces per Month
Port FOB shenzhen port
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	EASTOPS
Model Number	DFS-M040

Product Description

Specifications

Display Charging Function apply to:Mobile Phone camera , Tablet PC

Specifications

1.Item:Cell Phone Host series Alarm Device

2.FOB Shenzhen

3.Moq:1 pcs

4.T/T 100% before ship out all the goods

Cell Phone Host series alarm device

Specifications

Display Charging Function apply to:Mobile Phone camera , Tablet PC

8 Ports Alarm display stand security for mobile phone/carema/tablet PC

Basic Specification

Operating Voltage	9~12VDC
Stand-by Current Consumption	≤10.0mA
Activation Current Consumption	≤250mA
Bi Tone Output	≤120 db (Inner alarm), Optional: External Alarm or Speaker
Induction method	Contact separation alarm, disconnection alarm, USB jack separation alarm
Multi Targets	MX-364 (4 targets), MX-366 (6 targets) , MX-368 (8 targets)
3 Different Display Selectable	A.Metal Display Frame with USB Demo-Sensor B.Acrylic Display Frame with USB Demo-Sensor C.USB Demo-Sensor alone

Features:

Quick Reaction speed, pull or cut the USB cable, the Alarm warning.
With self-test function design, the factory settings to default the port is turned off, the alarm power USB port to connect the device host to detect the port, and take the initiative to close the idle port (idle port will automatically turn off, not man-made blockage), access device port detected automatically in the security state
Once the alarm has been triggered, restitution ca not disarm, the alarm must be reset by host key to disarm the alarm (press remote control red key 2 seconds to relief). With very higher safety factor, it can protect customer’s property.
Built-in alarm horn, high-volume alarm speaker is hidden inside the chassis of the host, so you can avoid destruction of the thief, such as the possibility of failure to cut the external alarm horn line, greatly improving security. (If necessary, user can add an external speaker on the wall or easy to hear the alarm sound, the external speaker jack plug into the rear side host).
With Remote function, easy to use (can order extra remote controller, if necessary).
LED light display each port current status.
USB interface, Ring Type, Mini End selectable, the cable length can be requested.
Wide range Application: Digital store, Electronics stores or exhibition in notebook, Tablet PC, Cameras, Smart phone, MP3, MP4 and the GPS and other exhibits anti-theft and reusable

Caution:

The host of the alarm should be placed in a more hidden and usually do not often encounter while on the other articles below, to avoid the alarm sound to be concealed.
Open daily alarm and be sure to check the connection is connected, just open for the proposed increase in security should be reset once to do self-inspection, self-test and observe the corresponding port light is lit.

Operating Step:

Connect one end of the cable to the alarm (USB port), the other end connected to the object.
The Adaptor jack plug into the alarm (on rear side).
The power supply plug into AC outlet, the alarm horn chirping sound, the power is ON, the alarm panel turn ON indicator LED corresponding port, the host is already in the security state (in active position).
Press red key on remote control to relief alarm, the alarm panel LED turns OFF.
If the installation of equipment to port which way the light does not illuminate, indicating which way is not connected, reconnect until the LED lights ON.
When the anti-theft device was break, or off line, the host immediately chirping alarm, while the corresponding port indicator light flashes, the staff on duty should be checked in the equipment of the ports and pay attention to whether there is "theft" by. Need to disarm the alarm status; you can press the Reset button (or remote button) to lift alarm.

Package Included:

FC165A (Remote Control Smart Alarm).
FC165u(USB mini End cable, length ~6 feet).
SM-0222 (Universal Adaptor 12Vdc 1,000mA).
FC165 r (Remote Control) optional.
FC165PMD(Smart Phone Metal Display) optional.
FC165CMD (Camera Metal Display) optional.
FC165TAD(Tablet Acrylic Display) optional.
