160tons press brake 8x4000mm Hydraulic cnc bending machine High quality
BRIEF INSTRUCTION:
1. Steel-welded construction,vibration to eliminate stress, with high strength and good rigidity.
2. Hydrualic top-drive,steadiness and reliability.Mechanical stop,steel torsion bar maintain synchronization,high precision.
3. Motorize-adjustinf device of backgauge and rams stroke,fine adjusting by handwheel,numberical display.
4. Deflection compensation unit installed on the top die.manual crowned die holder is adopted for the machine above 250 ton length 4000 mm.
5.Travels of rear block stop ( x ) slide block ( y) are all controlled by computer automatically.
6.Rear Block stop adopts ordinary screw mandrel or precision screw mandrel unilateral to eliminate the transmission clearance. and adopts linear duideway ,servo motor.
COMPONENTS :
Item |
Description |
Operation System |
CNC100,RT200,E200,DA41,DA52 DA56,DA65 |
Oil pump(Gear Pump) |
Chengjie(Shanghai) |
Hydraulic elements |
Rexroth (Germany)/Omega(U.S.A.) |
Electric parts |
Siemens (Germany) |
Motor |
Siemens(Germany) /Hengli (Nantong) |
Main Seal |
Valqua/Nok(Japan) |
Moulds |
Beleite (Jiangsu) |
All components also can supply according to client's requirement.
SPECIFICATION WC67k-160t/4000
|
unit |
Value |
Nominal Pressure |
KN |
1600 |
Length of working Table |
mm |
4000 |
Distance between uprights |
mm |
3200 |
Throat depths |
mm |
320 |
Ram Stroke |
mm |
200 |
Motor power |
KW |
11 |
OUR FACTORY
CNC SYSTEM:
BALL SCREW AND LINEAR GUIDEWAY
PRODUCTS
CAN WORK-PIECE PROCESSING:
PRODUCING PROCESS:
