aluminum shell oem constant current outdoor led power supply
Specifications:
- input:100-265vAC / 47-63HZ
- model: SMT-120-1050CW
- output: 100-120v @1050mA 126watt
- cover material: aluminium housing
- waterproof rate: IP67
- unit weight: 1210g/pcs
- product size: 186*68*43 mm
- box size:315*215*210mm
- pack qty: 10pcs/ctn
- gross weight: 12kg/ctn
- wire requirements:18AWG*20CM
- CE,UL, ROHS approval
- 2 years warranty
- (We promise to replace new ones to you if there is any defective happen during the warranty period)
Features:
- High efficiency,save energy ,protected environment
- High stability and low ripple, increase light efficiency and decrease light attenuation
- Meet to safety standard and EMC
- Assure LED stability long lift and light efficiency by constant current
- Passed high, low temperature and waterproof testing.
- Integrity protection,over loading, over voltage over current
- 8Hrs and 100% full load burn-in test.
- Case material--aluminium housing
- Cooling by free air convection
- High reliability designing solution
- Suitable for LED lighting and moving sign applications
Environment:
- Working Temperature : -40 ~ +60°C
- Working Humidity : 20 ~ 90% RH non-condensing
- Storage Temp. , Humidity : -40 ~ +80°C , 10 ~ 95% RH
- TEMP. Coefficient : ±0.03%/°C (0 ~ 50°C)
- ibration : 10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
Safety:
- Safety Standards : IEC 61347 –2–11 , IEC 61347 –1 , IEC 60529
- Withstand Voltage : I/P-O/P: 3000KVAC
- Isolation Resistance : I/P-O/P:100M Ohms/500VDC
Product parameters:
|
Model
|
Input voltage (vAC) |
Working Frequency (Hz) |
Output voltage (v) |
Output Current (A) |
Output power (W) |
Working
Temp. |
Protection
grade |
SMT-045-2000CW |
100-265v |
47~63Hz |
30-45VDC |
2000±50mA |
90W |
-25~50°C |
IP67 |
SMT-042-2400CW |
100-265v |
47~63Hz |
20-42VDC |
2400±50mA |
100W |
-25~50°C |
IP67 |
SMT-100-1050CW |
100-265v |
47~63Hz |
80-100VDC |
1050 ±50mA |
105W |
-25~50°C |
IP67 |
SMT-120-1050CW |
100-265v |
47~63Hz |
100-120vDC |
1050±50mA |
126W |
-25~50°C |
IP67 |
SMT-084-1200CW |
100-265v |
47~63Hz |
65-84VDC |
1200±50mA |
100W |
-25~50°C |
IP67 |
SMT-072-1400CW |
100-265v |
47~63Hz |
60-72VDC |
1400±50mA |
100W |
-25~50°C |
IP67 |
SMT-050-2000CW |
100-265v |
47~63Hz |
30-50vDC |
2000±50mA |
100W |
-25~50°C |
IP67 |
SMT-036-2800CW |
100-265v |
47~63Hz |
25-36VDC |
2800±50mA |
100W |
-25~50°C |
IP67 |
| Packing | |||||||
| N.W./pcs | G.W/ctn | Qty/ctn | Carton Size(mm) | ||||
| aluminum shell oem constant current outdoor led power supply | |||||||
| 1210g/pcs | 10kg/ctn | 12pcs | 315*215*210 mm | ||||
Packing:
Shipping
What kind of LED Driver/Power Supply We do??
We specialized in constant voltage & current LED drivers, 010v/triac/DALI dimmable led drivers, enclosure power suppliers, power adapters.
|
Triac CC&CV Dimmable Series
|
0-10V CC&CV Dimmable Series
|
DALI CC&CV Dimmable Series
|
|
Wall-mount Power Adapter
|
HOME
|
Desktop Power Adapter
|
|
Constant Voltage Series
|
Enclosue Power Supply
|
Constant Current Series
|
Our team
What Service we can supply??
-
All inquiries will be replied within 24 hours
-
Professional manufacturer,welcom to visit our website
- OEM/ODM avaliable:
A.Print logo on our product;
B. Customized specification; - After Sales-Service:
A. All products will have 100% burn-in test and strictly quality test before shipping;
B. Fast Delivery: 3-7days for samples, 15-20 days for bulk production; - High efficiency,long life span,reasonable&competetative price,fast lead time;
- We have our engineer team, if you have any question about your LED applications, let us know freely.
Frequently Asked Questions
Q1. What's the trade terms you can do??
A1: We accept EXW,FOB..(Optional)
Q2. What's shipping mode can we choose?
A2: Express, Ocean and air transportation (optional).
Q3. What's the MOQ?
A3: Our MOQ is 10pcs. better price for large quantity;
Q4. What can you do if the product is broken?
A4: We promise to replace new ones to you if there is any defective happen during the warranty period.
Q5. Can i get products with my own logo??
A5: Sure, you can, MOQ is 500pcs.
Q6. Can i get a sample for testing??
A6: Sure, but sample fees should be charged on your account.
Q7. What's the mormal lead time??
A7: 7 working days for samples, 15 working days for mass production.
Q8. What's the payment conditon?
A8: T/T in advance or 30% deposit and 70% before delivery (optional)
Q9. What's the Payment do you have?
A9: We accept payment be sent via T/T, L/C, Trade Assurance, WESTERN UNION, PAYPAL.
