700ma constant current led driver power supply manufacturer
| SPECIFICAION | ||||
| MODEL | SMT-040-0500CW | SMT-060-0350CW | SMT-030-0700CW | |
| OUTPUT | DC VOLTAGE | <45V | <45V | <45V |
| RATED CURRENT | 500mA | 350mA | 700mA | |
| VOLTAGE RANGE | 25-40V | 30-60V | 20-30V | |
| RATED POWER | 20W | 20W | 21W | |
| RIPPLE&NOISE(max) | ||||
| CURRENT TOLERANCE | ±5% | ±5% | ±5% | |
| LINE REGULATION | ±5% | ±5% | ±5% | |
| LOAD REGULATION | ±5% | ±5% | ±5% | |
| INPUT | VOLTAGE RANGE | 90-265VAC | 90-265VAC | 90-265VAC |
| FREQUENCY RANGE | 47-63Hz | 47-63Hz | 47-63Hz | |
| POWER FACTOR(Typ.) | >0.95 | >0.95 | >0.95 | |
| EFFICIENCY(Typ.) | >86% | >86% | >86% | |
| AC CURRENT(Typ.) | 0.15A/110V,220VAC | 0.15A/110V, 220VAC | 0.15A/110V, 220VAC | |
| PROTECTION | SHORT CIRCUIT |
Protection type:Hiccpe mode,recovers automatically after condition is removed |
||
| OVER CURRENT | Protection | |||
| OVER HEAT | Protection | |||
| ENVIRONMENT | WORKING TEMP. | -30~+50℃ (Refer to output load derating curve) | ||
| WORKING HUMIDITY | 20~99% RH non-condensing | |||
| STORAGE TEMP.,HUMIDITY | -40~+80℃,10~99%RH,IP67 | |||
| SAFETY&EMC | SAFETY STANDARDS | EN61347-1;EN61347-2-13;SELV | ||
| WITHSTAND VOLTAGE | I/P-O/P:2KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC | |||
| EMC Test Standards | EN55015;EN61000-3-2;EN61000-3-3; | |||
| EN61547;EN61000-4-2,3,4,5,6,8,11; | ||||
FEATURE:
1.Protections:Short circuit/Overload/Over temperature
2.Cooling by free air convection
3.100% full load burn-in test
4.Suitable for LED lighting
5.Products through CE, UL, RoHS Certification
6.2 years warranty
7.PF>0.9 / Efficiency> 86%
NOTE:
1.All parameters NOT specially mentoned are measured at 110V, 220VAC input,rated load
and 25℃ of ambient temperature.
2.Ripple&noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire
terminated with a 0.1uf&10uf parallel capacitor.
3.Tolerance:includes set up tolerance,line regulation and load regulation.
What kind of LED Driver/Power Supply We do??
We specialized in constant voltage & current LED drivers, 010v/triac/DALI dimmable led drivers, enclosure power suppliers, power adapters.
|
Triac CC&CV Dimmable Series
|
0-10V CC&CV Dimmable Series
|
DALI CC&CV Dimmable Series
|
|
Wall-mount Power Adapter
|
HOME
|
Desktop Power Adapter
|
|
Constant Voltage Series
|
Enclosue Power Supply
|
Constant Current Series
|
What kind of power cords we can help you fix in our LED Driver/Power Supply??
Answer: We can help you fix / find all kinds of power cords to our drivers as per your request, for example:
Smarts Electronics, the led driver manufacturer located in Quanzhou,has 6 years trade experience in Alibaba.
We have 7 kinds of led drivers or led power supply:
1.Constant Voltage LED Driver;
2.Constant Current LED Driver;
3.Triac CC&CV Dimmable LED Driver
4.0-10v CC&CV Dimmable LED Driver
5.DALI CC&CV Dimmable LED Driver
6.Power Adapter
7.Switching Power Supply
All of our drivers are got UL/cUL CE ROHS listed .OEM Welcome.
Our led drivers are widely used for:
1.Indoor LED illuminating lights
2.LED Neon, LED urban Decoration
3.LED Lighting Advertising,LED Display
4.Safety Protection Apparatus
5.Telecommunications, Networks
6.Vehicle Lights, Controller Panels
our market:
Our major markets are in EU & North America,it takes about 85% markets share. view transaction history
factory & equipments view:
certifications:
CE, UL/CUL, ROHS approval.
What Service we can supply??
-
All inquiries will be replied within 24 hours
-
Professional manufacturer,welcom to visit our website
- OEM/ODM avaliable:
A.Print logo on our product;
B. Customized specification; - After Sales-Service:
A. All products will have 100% burn-in test and strictly quality test before shipping;
B. Fast Delivery: 3-7days for samples, 15-20 days for bulk production; - High efficiency,long life span,reasonable&competetative price,fast lead time;
- We have our engineer team, if you have any question about your LED applications, let us know freely.
Frequently Asked Questions
Q1. What's the trade terms you can do??
A1: We accept EXW,FOB..(Optional)
Q2. What's shipping mode can we choose?
A2: Express, Ocean and air transportation (optional).
Q3. What's the MOQ?
A3: Our MOQ is 1pcs. better price for large quantity;
Q4. What can you do if the product is broken?
A4: We promise to replace new ones to you if there is any defective happen during the warranty period.
Q5. Can i get products with my own logo??
A5: Sure, you can, MOQ is 500pcs.
Q6. Can i get a sample for testing??
A6: Sure, but sample fees should be charged on your account.
Q7. What's the mormal lead time??
A7: 7 working days for samples, 15 working days for mass production.
Q8. What's the payment conditon?
A8: T/T in advance or 30% deposit and 70% before delivery (optional)
Q9. What's the Payment do you have?
A9: We accept payment be sent via T/T, L/C, Trade Assurance, WESTERN UNION, PAYPAL.
How to Contact US??
|
Tel.:+86 (595) 2286 3721 /Fax:+86 (595) 2246 5526
Skype: sales5smt / Whatsapp/Phone: +86 13635216739 |
| ***Any questions,Just feel free to click "send" to contact with me.^-^*** | |
