110v 11w 15w 30w landscape lighting electric dimmable transformers
Model |
SMT-090-0350CT |
SMT-048-0500CT |
SMT-036-0700CT |
SMT-036-0900CT |
|
Output |
DC Current |
350mA |
500mA |
700mA |
900mA |
Current Accuracy |
±5% |
||||
Voltage Range |
50-90V |
30-48V |
20-40V |
20-36V |
|
Rated power |
30W |
30W |
25W |
32W |
|
Input |
Voltage Range |
170~250VAC/(90-130VAC For North America Markets ) |
|||
Frequency Range |
47~63HZ |
||||
Power Factor (Typ.) |
PF>0.93/110V ; PF>0.95/220V ; PF>0.94/250V |
||||
Full Load Efficiency(Typ.) |
85% |
86% |
85% |
85% |
|
AC Current(Typ.) |
0.14A/110VAC 0.12 A/220VAC 0.01A/250VAC |
||||
Leakage current |
<0.27mA/110VAC; <0.25mA/220VAC |
||||
Protection |
Short Circuit |
Hiccup mode, recovers automatically after fault condition is removed. |
|||
Over voltage |
<270VAC |
||||
Environment |
Working TEMP. |
-40~+60℃ |
|||
Working Humidity |
20~90%RH,non-condensing |
||||
Storage TEM.,Humidity |
-40~+80℃,10~95%RH |
||||
efficient |
±0.03%/℃(0~50℃) |
||||
Vibration |
10~500Hz,2G 10min./1 cycle,period for 60min. each along X,Y,Z axes |
||||
Safety&EMC |
Safety standards |
EN-60950-1, EN-61347-1-2 |
|||
Withstand voltage |
I/P-O/P:3.75KVAC |
||||
Isolation resistance |
I/P-O/P:100MΩ/500VDC/25℃/70%RH |
||||
EMC EMISSION |
Compliance toEN55015,EN61000-3-2 (>50%load) |
||||
EMC IMMUNITY |
Compliance to EN55015,EN61000-4-2,3,4,5,6,8,11,A light industry level (surge 4KV) |
||||
Others |
Weight |
0.34Kg/pcs |
|||
Size |
180*60*34mm (L*W*H) |
||||
packing |
324*298*176mm |
||||
Features:
- Output constant current
- Input range :90-135VAC / 170-265VAC
- Built-in PFC function
- Efficiency > 84%
- Protections:Short circuit/over Voltage
- Fully isolated plastic case
- Easy installation
- Cooling by free air convection
- Work with leading edge and trailing edge TRIAC dimmers
- Strong compatibility, flicker-free dimming
- Suitable for LED lighting and moving sign applications
- Compliance to worldwide safety regulations for lighting
- CE,UL/cUL, RoHS approval
- 3 years warranty
Note:
- All parameters NOT specially mentioned are measured at 110V/230VAC input , rated load and
25℃of ambient temperature. - Ripple& noise are measured at 20MHz of bandwidth by using a 12”twisted
pair-wire terminated with a 0.1uf &47uf parallel capacitor. - Tolerance:includes set us tolerance,line regulation and load regulation .
21~32W triac dimmable driver Mechanical Specification:
- Input with connecting terminal
- Output with connecting terminal
- Note: Any other requests we can customized.
Dimming Operation
- Output constant current level can be adjusted through input terminal of the AC phase line(L) by connection a triac dimmer.
- Compatible with Leading edge or tailing edge triac dimmers.
- please try to use the small power dimmer, have access to a wider dimming range, high-power dimmer is difficult to achieve the output current to zero
Derating Curve
- Load carried in accordance with the load derating curve, according to the ambient temperature derating, in order to extend the service life.
