high quality 30W driver led dali constant voltage mini transformer 12v ul listed
Specification:
- Modle: SMT-012-030VM
- Input voltage:100~265vAC 47-63HZ
- Output :12v @0-2500mA 30w
- working mode: constant voltage
- dimming mode: DALI dimmable
- Case material:plastic housing
- Waterproof rate: IP40
- Efficiency:> 87%
- PF:>0.9
- product size: 140*45*28mm
- unit weight: 400g
- CE, UL&CUL, ROHS approval
- 3 years warranty
- (We promise to replace new ones to you if there is any defective happen during the warranty period)
Product Features:
Universal AC input (100~265V/170-375V)
Suitable for LED lighting and moving sign applications
designing standard: Ul1310 Class 2 power unit
Built-in active PFC function
- High efficiency,save energy, protected environment.
- High stability and low ripple, increase light efficiency and decrease light attenuation.
- Meet to safety standard and EMC
- Assure LED stability long lift and light efficiency by constant voltage.
- Integrity protection,over loading, over voltage ,over current.
- Protections:Short circuit/Overload/Over temperature
- Cooling by free air convection
- 100% full load burn-in test
Environment parameter:
1. Working temperature:-40 -50°C
2. Store temperature:-40 -85°C
3. Working humidity:20-95%
Safety :
1.Safety Standards : IEC 61347 –2–11, IEC 61347 –1 , IEC 60529
2.Withstand Voltage : I/P-O/P: 3000KVAC
3.Isolation Resistance : I/P-O/P:100M Ohms/500VDC
Product parameters:
| item no. |
input voltage (V AC) |
Input Frequence (Hz) |
Output Voltage (vDC) |
Output current (Amp) |
Output Power (Watt) |
IP rate |
| SMT-012-030VM | 100-265Vac | 47-63Hz | 12v | 0-2500mA | 30w | IP40 |
| SMT-024-030VM | 100-265Vac | 47-63Hz | 24v | 0-1250mA | 30w | IP40 |
| SMT-012-045VM | 100-265Vac | 47-63Hz | 12v | 0-3750mA | 45w | IP40 |
applications:
Our products are widely used in various industries, such as
- indoor/outdoor LED illuminating lights,
- LED Neon,
- LED urban Decoration
- LED Lighting Advertising,
- LED Display,
- Safety Protection Apparatus,
- Telecommunications,
- Networks,
- Vehicle Lights, Controller Panels, etc.
240v constant voltage triac dimmable 6w led mini 12v 0.5a transformer
high quality constant current 50w 60w 700ma dimmable led driver for led lamps
12w 15w 17.5w 300ma 500ma 700ma constant current dimmable led driver UL standard
Can you help me fix my own power cords???
Answer: we can help you fix / find all kinds of power cords to our drivers as per your request, for example:
what is the packing situation ??
Packing:
Shipping
Why choose Quanzhou Smarts Electronic & Technology Co.,Ltd??
1). Our major markets are in EU & North America,it takes about 85% markets share,that to say we do high quanlity
power suppliers only.
2). Most of our products are approved with UL/CE/Rohs approval, our ULfile#E365202.
3). We give 3 years warranty
4). We accept trial orders begining..
5). We have an area of 2000 square meters factory, about 300-500 production staff. ..
Website:
our team:
certifications:
CE, UL/CUL, ROHS approval.
factory & equipments view:
Why choose us?
1. We are UL/cUL audited LED drivers/power supplies enterprise in China.
2. Alibaba assessed 6 years Gold Supplier and more than 10 years LED industrial experience. It will guarantee your order 100% safe!
3. Price is negotiable if you have large quantity demand.
4. 100% QC inspection Before Shipping.
5. Best Quality & Best Service with Competitive price.
6. Shipping will be the most economical for you and freight cost is informed in advance for your consideration.decision for the shipping terms will be made according to your requirements.
7. We have our engineer team, if you have any question about your LED applications, let us know freely, we will give you the best solution.
8. Our trade manager is online 12 hours. and we will reply your inquiry within 8 hours.
9. OEM design & OEM packing welcome.
10. Samples will be ready within 7 working days
Q1. What's type power supply do you have?
Answer: We specialized in constant voltage & current LED drivers,0-10v/triac/DALI dimmable led drivers, enclosure power suppliers, power adapters.
Q2. What's shipping mode can we choose?
Answer: 1.FedEx/DHL/UPS/TNT/Express for samples;
2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;
3. Customers specifying freight forwarders or negotiable shipping methods!
Q3. What's the MOQ?
Answer: Our MOQ is 500pcs, but we accept your trail order/small order, no problem.
Q4. What can you do if the product is broken?
Answer: We promise to replace new ones to you if there is any defective happen during the warranty period, but we need pictures or video to prove the defective comes from our quality problem.
Q5. How about the protection of product?
Answer:Most of our products have protection of short-circuit, overload,over voltage, over current and reserve polarity. About the specific product, please consult our sales stuff.
Q6. How about the transportation?
Answer:For small order,express will be best.And for bulk order,sea ship way is best but take much time. For urgent orders,we suggest via air to airport plus our ship partner send to your door. We will cooperate with your choice.
Q7. What's the Payment do you have?
Answer: To assure you the maximum comfort and satisfaction, Currently, you can pay via T/T, L/C, WESTERN UNION, PAYPAL. More payment options will be added in the near future
Our goal is to provide you the right product and make you satisfied, so please don’t hesitate to contact us !
We will always be here and try our best to provide you our best service !
Waiting for your kind inquiry !
