7 Inch VGA and RS232 TFT LCD Touch Screen Monitor

Name: 7 Inch VGA and RS232 TFT LCD Touch Screen Monitor
Brand: AZUQI
SKU: 134444269
Availability: InStock

Azuqi International Limited

US$ 69 - 109 MOQ: 50 Pieces

Key Specifications

Products Status:

Stock

Application:

Desktop

Screen Size:

Other, 7 inch

Payment & Shipping

Payment Methods:

Port of Shipment:

Hong Kong

Delivery Detail:

Delivery time depends on order quantity.

Products Status Stock

Application Desktop

Screen Size Other, 7 inch

Response Time 12ms

Brightness 300cd/m

Interface Type D-Sub, RS232C

Contrast Ratio 400:1

Resolution Other, 1024 x 768 @ 75Hz, 800x400@ 60Hz

Widescreen Yes

Panel Type TFT

Pixel Pitch 0.1905m

Brand Name AZUQI

Model Number AKA-070V3

Place of Origin Guangdong, China

Specifications

7 inch mini LED monitor
Connectors: VGA/DC12V

7 inch mini VGA Input CCTV LED monitor

Application Field:

1. SOHO Offices

2. Shopping Mall

3. Government Users/Home User

I. Specifications:

Model No.	AKA-070V3
Display	Screen Size	7'' (16:9) Digital panel
	Max. Resolution	1024 x 768 @ 75Hz
	Pixel Pitch	0.1905m
	Brightness	300cd/m²
	Contrast Ratio	400:1 Typical
	Viewing Angle (U/D/L/R)	70°/90°/85°/85°
	Display Color	16.7m
	Response Time	12ms Typical
	Video System	NTSC / PAL
Interface	Solution No.	PC Solution
	VGA Input	x1
	DC 12V Input	x1
Features	Source	VIDEO 1/VIDEO 2 /VIDEO 3
Features	Multi Language	English, Chinese
Audio	Built-in Speakers	2
Cabinet	Wall mount	VESA DDC 1/28
	Material	ABS Plastic
	Base Stand	Desk Top Stand
Circumstance	Operating Temperature	0 ~ 50° C / 32 ~ 122° F
Circumstance	Storage Temperature	-20 ~ 60° C / -4 ~ 140° F
Packing	Unit N.W./G.W.	Approx. 1.3KG/1.5KG
Packing	Gift Box Dimension	300 x 218 x 85mm (LxWxH )
Regulations	RoHs, FCC , CE, C-tick, and so on.
*Specifications are subject to change without notice.

Model No.	AKA-070V3T (Touch Screen)
Display	Screen Size	7''(16:9) Digital panel
	Max. Resolution	1024 x 768 @ 75Hz
	Pixel Pitch	0.1905m
	Brightness	300cd/m²
	Contrast Ratio	400:1 Typical
	Viewing Angle (U/D/L/R)	70°/90°/85°/85°
	Display Color	16.7m
	Response Time	12ms Typical
	Video System	NTSC / PAL
Interface	Solution No.	Touch Solution
	VGA Input	1
	DC 12V Input	1
	Touch screen	Serial (Rs232) or USB
	DOS/Window 9X ME,2K; XP Vista NT Windows;CE/LINUX/Mac
Features	Source	VIDEO 1/VIDEO 2 /VIDEO 3
Features	Multi Language	English, Chinese
Audio	Built-in Speakers	2
Cabinet	Wall mount	VESA DDC 1/28
	Material	ABS Plastic
	Base Stand	Desk Top Stand
Circumstance	Operating Temperature	0 ~ 50° C / 32 ~ 122° F
Circumstance	Storage Temperature	-20 ~ 60° C / -4 ~ 140° F
Packing	Unit N.W./G.W.	Approx. 1.3KG/1.5KG
Packing	Gift Box Dimension	300 x 218 x 85mm (LxWxH )
Regulations	RoHs, FCC , CE, C-tick, and so on.
*Specifications are subject to change without notice.
