10.4 Inch Tft Small Cctv Monitors

Name: 10.4 Inch Tft Small Cctv Monitors
Brand: AZUQI
SKU: 134443999
Availability: InStock

Azuqi International Limited

US$ 70 - 90 MOQ: 100 Pieces

Key Specifications

Products Status:

Stock

Application:

Desktop

Screen Size:

Other, 10.4''

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen/hongkong

Delivery Detail:

Delivery time depends on order quantity.

Products Status Stock

Application Desktop

Screen Size Other, 10.4''

Response Time 8ms

Brightness 370cd/m

Interface Type D-Sub, HDMI

Contrast Ratio 1000:1

Resolution Other, 800x600

Widescreen No

Panel Type TFT

Pixel Pitch 0.33mm

Brand Name AZUQI

Model Number AKA-104MA

Place of Origin Guangdong, China

Specifications

small cctv monitors
Resolution:800x600
Connectors: VGA/ Audio/HDMI/BNC
Regulations: RoHS, CE (EMC & LVD), FCC, C-TICK

10.4 inch tft small cctv monitors

Specification
Model No.		AKA-104MA
Display	Screen size	10.4'' (4:3)
	Panel type	TFT Color LCD
	Pixel Pitch	0.33mm
	Brightness	380 cd/m2
	Contrast ratio	300:1 typical
	Viewing Angle(U/D/L/R)	65/65/45/60
	Display color	262K
	Response Time	8ms
	Power Consumption	Approx. 15 Watts
	Video system	NTSC / PAL
Interface	Solution No.	M2 (Economy style)
	Video 1 Input	CVBS Input(BNC type)x1
	Video 2 Input	CVBS Input(BNC type)x1
	Video 2 Output	CVBS Output(BNC type)x1
	PC-RGB Input	VGA (15Pin D-Sub)x 1
	Audio Input	Stereo 3.5mm input x1
	Audio Output	Stereo 3.5mm Output x1
	HDMI Input	1
	DC 12V Input	1
Features	Built in Comb Filters	2D
	Built in De-interlace	3D
	Source	PC / Video1 / Video2 / HDMI
	Multi-Language	English, Chinse,French ,German,
	Multi-Language	Italian , Portuguese , Spanish
Audio	Built in Speakers(Option)	2
Cabinet	Color	Black
	Material	ABS Plastic
	Wall Mount	VESA
	Base Stand	Desktop Stand
Circumstance	Operating Temperature	0°C ~ 50°C / 32°F~122°F
Circumstance	Storage Temperature	20°C~60°C / 4°F~140°F
Packings	Unit N.W./G.W.	Approx. 1.2KG/2KG
Packings	Gift Box Dimension	330x133x355 mm (LxWxH)
Regulations	RoHs , FCC , CE , C-tick , and so on.
Specification are subject to change without notice
