non rising stem rubber lined gate valve
1.Technical Data:
(1) Nominal Diameter DN(mm):40(1-1/2’’)~1600(64’’)
(2) Nominal Pressure PN(MPa): 1.0~1.6
(3) Testing Pressure PN(MPa): Shell: 1.5~2.4 Sealing: 1.1~1.76
(4) Suitable Mediums: Water,Steam,Oils,Gas
(5) Working Temperature:-20~+250°C
2.Design consideration :
Design Standard: API 600 , EN10434 , DIN3352
Face to Face: ASME B16.10, EN 558, DIN3202
End Flange: ASME B16.5(ASME B16.47), EN1092, DIN2533
Buttwelding Ends: ASME B16.25, EN12627, DIN3239
Inspection and Test: API 598, en12266, DIN3230
3.Body Meterial could be:
Ductile cast iron / Cast steel / stainless steel 304/316
1.Packing:plywood cases,or according to the customers' requirements
2.Shipment:Within 20 days after your po.
1.Best price with high quality,
2.18 months Guarantee Period.
3.The standard could be ANSI,DIN,GB,ISO,GOST and so on
1.More than 40 years Professional Experience.
2.The sample of material will be preserved more than 10 years.
3.We have obtained safety approval of API,CE,ISO.
1.Standard.
2.Size.
3.Material .
4.Connection type.
5.Medium.
6.Temperature.
Quality achievement brand, honesty cast the future!
Would like to know more ,contact me please!
