Casting piston check valve/valve wholesaler in china
1.Brief Description:
1).Model:H41H/Y/W
2).Size:2"-20"
3).Pressure:class 150lb-class 2500lb
4).Temperature:-20℃~+200℃
5).Medium:water,acid,steam,petroleum etc
2. Design Standard
Design and manufacure:API 6D
Structural length: ASME B16.10
Flange connection:ASME B16.5
Test and inspection:API 598
3. Main Properties
Testing pressure | Nominal pressure(Mpa) | |||||
LB | 150LB | 300LB | 600LB | 900LB | 1500LB | 2500LB |
Strength test | 3.1 | 7.8 | 15.3 | 23.1 | 37.8 | 63.4 |
Sealing test | 2.2 | 5.5 | 11.0 | 16.5 | 27.5 | 46.2 |
Air test | 0.5~0.7 | |||||
Working temperature | PTFE≤150°C, | |||||
4.Main Spare Parts
No. | Part name | Material |
1 | Body,Bonnet | WCB,CF8,CF3 |
2 | Disc | wcb+F6 |
3 | Gasket | Flexible Graphite |
4 | Sealing | Stainless steel |
Shipping:20 days after order confirmed.
Packaging:Plywood case.
1.Good quality and low price.
2.Good after-sale service.
3.Bring the finest goods to customer is our ultimate goal.
4.Products are exported to various countries.
