72 core jumper MPO-MPO
MPO/MTP patch cord is a kind of high density cable assemblies which can be used in CO of FTTH. It save space and easy to maintain.
Features:
Low insertion loss, high return loss
MT based Multi-fiber Connector up to 12 fibers
High credibility and stability
Good in repeatability and exchangeability
Standard: Telcordia GR-1435-CORE compliant
Application:
Testing equipment
FTTX+LAN
Optical fiber CATV
Optical communication system
Telecommunication networks.
AVAILABILITY:
Ribbon and bundle cable available;
Patch cord, pigtail cable assemblies available.
MT-MT ribbon patch cord is available.
MPO Loopback available
Specification:
MPO/MTP’s spec items. |
SM(APC Polish); SM(UPC/Flat Polish) |
MM(PC/Flat Polish) |
||
Test Wavelength |
1310nm |
850nm |
||
Insertion loss |
Standard |
Low loss |
Standard |
Low loss |
≤0.5dB |
≤0.35dB |
≤0.5dB |
≤0.35dB |
|
Return loss |
UPC≥50dB;APC≥60dB |
≥30dB |
||
Durability |
<0.3dB typical change, 500 matings |
|||
Interchangeability |
≤0.2dB |
|||
Tensile strength |
>70N |
|||
Other connector’s Spec is the same as we mentioned in patch cord’s html.
Packaging & Shipping
one piece in a PE Bag
hundreds piece in a cartoon of 54*35*39cm.
other size carton is available too.
OEM service available
