10&100&1000M Media converter
This product supports IEEE802.3 10 Base-T standard/IEEE 802.3u 100Base-TX/FX standard/IEEE 802.3z 1000Base-TX/FX standard, as well as full duplex and half duplex mode.
Installation
1. Interface
RJ-45 interface
The transmission media adopts CAT5 twisted-pair with typical length of 100 meter.
It features the function of automatically identifying the through line and cross wire
Fiber interface
SC/ST fiber interface is of duplex mode type, including two interfaces, namely TX and RX.
When the two sets of optical transceiver are interfaced or connected to switch with fiber interface, the fiber is in cross connection, namely "TX-RX", "RX-TX" (direct butting for single optical fiber).
2. Connection
The network device (work station, hub or switch) with RJ-45 interface is connected to RJ-45 jack of optical transceiver through twisted-pair.
And the multi/single mode fiber is connected to SC/ST fiber interface of the optical transceiver.
Then switch on. The corresponding LED is on for correct connection. (See the table below for the LED indicator lamp)
Technical parameters:
1. Standard Protocol:
IEEE802.3 10 Base-T standard
IEEE 802.3u 100Base-TX/FX standard
IEEE 802.3z 1000Base-TX/FX standard
2.Connector:oneUTPRJ-45connector,one SC/ST connector
3. Operation mode: full duplex mode or half duplex mode
4. Power supply parameter:
outside: 5V DC 2A
built-in: 110-265V AC 48VDC
5. TP cable: Cat5 UTP cable
6 Transfer fiber:
multi-mode: 50/125, 62.5/125 or 100/140μm
single mode:: 8.3/125, 8.7/125, 9/125 or 10/125μm
Order info
Description |
Fiber mode |
Connector |
Wavelength |
Distance |
TX power(dbm) |
RX power(dhm) |
OMC-8110GMA-11-05-AS |
Multi-mode dual fiber |
SC |
850nm |
550m |
-17~-12 |
<=20.0 |
OMC-8110GMA-11-2-AS |
Multi-mode dual fiber |
SC |
1310nm |
2 Km |
-17~-12 |
<=20.0 |
OMC-8110GSA-11-10-AS |
Single-mode dual fiber |
SC |
1310nm |
10 Km |
-6~-12 |
<=21.0 |
OMC-8110GSA-11-20-AS |
Single-mode dual fiber |
SC |
1310nm |
20 Km |
-3~-8 |
<=23.0 |
OMC-8110GSA-11-40-AS |
Single-mode dual fiber |
SC |
1550nm |
40 Km |
-3~-0 |
<=25.0 |
OMC-8110GSA-11-60-AS |
Single-mode dual fiber |
SC |
1550nm |
60 Km |
|
|
OMC-8110GSA-11-80-AS |
Single-mode dual fiber |
SC |
1550nm |
80 Km |
>>1 |
<=27.0 |
OMC-8110GSB-11-10A/B-AS |
Single-mode single fiber |
SC |
A side:Tx1310nm/Rx1550nm |
10 Km |
-10~-5 |
<=20.0 |
OMC-8110GSB-11-20A/B-AS |
Single-mode single fiber |
SC |
A side:Tx1310nm/Rx1550nm |
20 Km |
-8~-5 |
<=23.0 |
OMC-8110GSB-11-40A/B-AS |
Single-mode single fiber |
SC |
A side:Tx1310nm/Rx1550nm |
40 Km |
-3~0 |
<=23.0 |
OMC-8110GSB-11-60A/B-AS |
Single-mode single fiber |
SC |
A side:Tx1310nm/Rx1550nm |
60 Km |
-3~0 |
<=23.0 |
Packaging
one piece in a paper box.
hundreds pieces in a larger cartoon.
Shipping
goods shipped by air or by land transporation.
1,Free samples can be provided.
2,OEM service
3,Nice payment terms.
4,high quality products
5,Competitive price,
6,fast delivery
7,New product priority sell
8,Optical Network Project Consultant.
9,New Products development for customer.
10,Cost-effective logistic solution can be chosen for you.
11,The specific sales person to serve our customers so that you can feel easy and efficient.
OMC industry co., limited, which was founded by an expert team, has been exporting FTTX passive products since 2007. We focus on providing innovative and integrated FTTX solutions for a variety of applications/Networks. Our capabilities include product/solution design, development, enhancement and integration. Our products are among the highest performing in the industry and truly represent the best values in the industry. We also offer training, pre and post-sales support. We help you select the right products for your Optical network’s needs.
Quality is life of OMC. Our firm commitment is to deliver world class product to our customers and forever exceed their expectations. We also offer Solid after sales support i.e. 3 years product warranty under no conditions
OMC treat our customers, suppliers, and employees as our respectable partners. We very happy to share our success with them. Offering best products to our customers, Long-term/Loyal partnership to our supplier and good salary/welfare to our employees. OMC also spare no effort to care our society and environment. With a grateful heart, OMC will go firmly to the bright way that we are longing for.
We hereby gather in OMC, with plentiful passion and professional techniques to service customers all over the world.
1,Can we get free samples?
Yes. Free samples can be offered for your test. You only need to pay the freight.
2,What is the quality of the products?
All the products are of high quality. We promise 100% recall policy if they are unqualified.
3,How will we do if we are not familiar with the optical products?
Don’t worry. We OMC has a team of experts who can offer professional suggestion for customer’s Optical network Project.
4,We are confused that the freight is too high.
Cost-effective logistic solution can also be chosen for you.
5,What is your quality control.
(1).source guarantee. We have our own long-term suppliers. All the products are POHS certificated and satisfy exporting quality level demand.
(2).quality test. It runs through the whole process from the Material to finished products. Such as package, surface, physical test, optical test. They are 100% tested.
(3)optical test. Our products are strictly tested in accordance with IEC and ITU standard.
(4)we have 30% spot test by Quality Assurance Department after the products finished.
