multi- daylight hydraulic press
1 Introduction
This machine is mainly used to foam and form EVA (PE, SBR) rubber, plywood,foam molding material which can widely used to make shoes, plastic foam flooring, insulation materials, luggage liner, sports protective material, diving suit material, life jackets materials.
2. we can make according to customer requires
2 Paremeter FRAME OR FOUR COLOMN TYPE
| Machine Name | Hot Press |
| Frame Style | Combination Frame |
| Quantity and Diameter of Cylinder | 2 units Φ360mm |
| Pressure | 200T/400T/500T/600T/800T ( customized) |
| Quantity of Openings | 8/10/11/12/15 Openings |
| Separation Between Layers | 70MM |
| Stroke of Cylinder | 560MM |
| No-load Closing Time | About 15s |
| Hydraulic System | Microcomputer Manually/Automatic Controlled |
| Hydraulic System Compression Resistance | 25MPa |
| Main Motor | 11KW |
| Pressurized Motor | 5.5KW |
| Main Pump | 1 piece of Shanghai Aviation 250 pump |
| Pressurized Pump | 10ml/rev plunger pump |
| Hot Platen Size | 2700*1370*42mm |
| Main Frame Steel Plate Thickness | 40mm,22mm,12mm |
| Upper, Bottom, Movable Crossbeam | 1000mm,900mm,400mm |
| Movable Crossbeam | 2700*1370*400mm |
| Dimensions of Main Frame | 3560*1370*3554mm |
| Weight | 26T |
4 detailed pictures
plywood production pictures
For FCL goods, we usually pack machines with stretched film and then load them to the
container. to ensure safety, we will fix machine with steel .
For LCL goods, we usually pack machines with standard wood boxes first, and then they will be transported .
1 Guarantee : 2 years ,manufacturer sell, We offer lifetime technical support
2After sales:
1 once problems appear, we will reply in 24 hours. And give solutions
2provide facory layout drawing . Engineers available to service machinery overseas; Send the engineers to debug the machines,Train your workers to use machine.
.
Qingdao Honghesheng Industry Co., LTD, manufacturer of rubber machine,which is located in the west coast of Qingdao economic district, with 10 million registered capital. The company covers an area of 5000 square meters with 26 professional and technical staffs and 5 senior engineers. The technical staffs have working experience in large tire enterprise who can design more suitable equipment for the customer as for tire production process. Also they can provide new factory site planning and other services.
The company’s main products are: Rubber kneader, rubber mixing mill, rubber sheet cooling machine, inner tube production line,tyre production line, vulcanizing press, waste tyre recycling plant…
welcome to visit our factory!
Leave your cellphong? Skype? whatsApp?viber? so that we can talk efficiently.
Contact Sophie for quotation NOW:
Skype: sophie.xiao3
Cell: +8613573826806 (whatsApp and viber)
