InMax 1.25Gbps SFP Optical Transceiver Modules 20Km,DDM

Name: InMax 1.25Gbps SFP Optical Transceiver Modules 20Km,DDM
Brand: InMax
SKU: 134395069
Availability: InStock

US$ 10 - 50 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

InMax

Model Number:

InMax-1

Shenzhen InMax Technologies Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen HK

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name InMax

Model Number InMax-1

Product Specification

1.25Gbps SFP Optical Transceiver, 20K m,DDM

1. Feature:

l SFP package with LC connector

l 1310nm FP laser and PIN photo detector

l Up to 20Km transmission on SMF

l +3.3V single power supply

l LVPECL compatible data input/output interface

l Low EMI and excellent ESD protection

l laser safety standard IEC-60825 compliant

l Compatible with RoHS

l Digital Diagnostic SFF-8472 compliant

2. Application:

l Ethernet

l Telecom

l Fiber Channel

3. Absolute Maximum Ratings:

Parameter	Symbol	Minimum	Maximum	Units
Storage Temperature	Tst	-40	+85	°C
Supply Voltage	Vcc	0	+3.6	V
Operating Relative Humidity	RH	5	95	%

4. Operation Environment:

5. Optical Characteristics:

(Ambient Operating Temperature 0°C to +70°C, Vcc =3.3 V)

Parameter	Symbol	Min.	Typ.	Max.	Units
Transmitter Section
Center Wavelength	lo	1260	1310	1360	nm
Spectral Width(RMS)	Dl	-	-	4	nm
Average Output Power	Po	-8	-	-3	dBm
Extinction Ratio	Er	10	-	15	dB
Rise/Fall Time(20%~80%)	Tr/Tf			0.26	ns
Total jitter	Tj			0.43	UI
Optical Eye Diagram	IEEE 802.3z and ANSI Fibre Channel Compatible
Receiver Section
Center Wavelength	lo	1260		1620	nm
Receiver Sensitivity	Rsen			-24	dBm
Receiver Overload	Rov	-3			dBm
Return Loss		12			dB
LOS Assert	LOSA	-36			dBm
LOS Dessert	LOSD			-24	dBm
LOS Hysteresis		0.5		5
