Specifications
Paper Cutting Machine Knife1.Auto counting and auto warning
2.100 times/min
3.PLC,Touch Screen
4.In stock
Servo Control One Roll DKHHJX-1100 High Precision Automatic Paper Cutting Machine Knife Usage:
This Paper Cutting Machine Knife is suitable for cutting the large coil packaging material,such as the paper, papaer plastic complex material and color printing complex material,etc This machine is widely used for application in the industries of paper processing and printing packaging.
Paper Cutting Machine Knife Function:
1,This Paper Cutting Machine adopts the servo motor (or stepless motor) to control the fixed-length cutting .It is equipped with the photoelectric tracing modifying system.
2,This machine integrates photo. electricity liquid and as a whole, PLC touching screen (manual or antomatic), and has the features operation,high-precision cutting,state operation and low noise.
3, The machine has the fenture of the motor frequency speed adjustment.
4.automation counting, giving an alarm when stop. and tension with digital indication.
Paper Cutting Machine Main technical parameters:
Model parameters | DKHHJX-1100 | DKHHJX-1300 | DKHHJX-1600 | ||
maximum diameter of raw materials | 1400mm | 1400mm | 1400mm | ||
The largest-cut width | 1100mm | 1300mm | 1600mm | ||
The accuracy | 20-1200mm | 20-1200mm | 20-1200mm | ||
Precision of fixed | ±0.2mm | ±0.2mm | ±0.2mm | ||
Productivity | 100 m/min | 100 m/min | 100 m/min | ||
Total power | 11kw | 13kw | 15kw | ||
Weight | 2300kg | 2600kg | 3000kg | ||
Applicable power | 380v/50Hz(three phases four wire) | ||||
Dimensions (mm) | 5500×1850×1200 | 5500×2100×1250 | 6000×2400×1250 | ||
Real Machine Pictures:
Paper Cutting Machine Magnetic Tension Control:
Machine Computer Control Plate: Touch Screen
The Round Knife for Cross-cutting :
Optional Device: Automatic Arranging :
Paper Cutting Machine Knife Complete Line:
Welcome Contact me or Visit us Anytime
We also can customized according the customer's require
FAQ:
1.Q:Are you a factory or trade company?
R:We are a factory for Paper Cutting Machine Manufacture
2.Q:Where is your company located?How can I visit there?
R:Our company is located in Ruian City,Wenzhou area,Zhejiang province,China.
About 1 hour by plane from Shanghai to Wenzhou,then 1 hour taxi to our place(5 hours by fast
train to Ruian station)
3.Q:what is the raw material does the machine ?
R:the material is Roll Paper
4.Q:who can answer my urgent questions about the machine?
R:leave a message when I am not online,will reply you within 24hours.
5.Q:how does your factory do regarding quality control?
R:our company policy is “quality first,customer first”.we have a QC manager whom check
the machine making from beginning to the end.
