4.3 inch Video Door phone Control Board with Monitor Display

Specifications

Input signal: 2 way CVBS
Resolution:480*(RGB)*272
View Angle(up/down/left/right):50/55/60/60
Brightness:> 350Cd/m2

     Security TFT-LCD Driver Board



HIGH-QUALITY 4.3INCH MODULE FOR MONITORS AND HOME SECURITY







 Application:





Building interphone, car reversing system







Industrial controlling system, medical equipment







Audiovisual equipment Car display, Portable DVD Player







Household Video door bell, Videophone, Digital Camera





Specifications







1. 4.3'' Digital TFT LCD Module
2. Use for display equipment
3. Input signal:2 way CVBS
4.Warranty: within 12months







Product Number	Silicon-P-004
Backlight	LED
Resolution	480(RGB)×272
View Angle ( up/down/left/right )	50/55/60/60
Brightness	> 350Cd/m2
Input Signal	CVBS
System Format	PAL/NTSC(Auto switch)
Supply Voltage	9V-15V
Rated Power	1.2w
Adjust Model	Menu adjust
PCB Structural Dimension(mm)	90(W)×48(H)×6.8(D)
Screen Size(mm)	105.5(W)×67.2(H)×2.9(D)
Operating Temperature	-20~70°C
Relative Humidity	5~95% RH
Storage Temperature	-30~80°C
Packing	bubble bag and standard export carton









Advantage :





Unique design,



Free for customer ordering starting LOGO,



Accepts order the CABLE lines,



OEM/ODM based on the customer demands.



we have many products, some are not showing on the internet. So, pls contact us,We'll recommend ur need iterm.
