480*272 4.3" TFT-LCD Driver Board Video Door Phone Board

Specifications

1.Application:

     Building interphone, car reversing system

   Industrial controlling system, medical equipment

     Audiovisual equipment Car display, Portable DVD Player

     Household Video door bell, Videophone, Digital Camera

2.Feature:

1)         Product Name: 4.3"TFT-LCD Driver Board

2)      Product number: Silicon-P-004

3)         Backlight: LED

4)         Resolution:480x(RGB)×272

5)         View Angle(up/down/left/right): 50/55/60/60

6)         Brightness:> 300Cd/m²

7)        Input signal: CVBS

8)         System format: PAL/NTSC(Auto switch)

9)         Adjust model: Menu adjust

10)     Power Supply Input: DC 9V-18V

11)     Rated power: 1.2W

12)     Display Dimension of LCD (mm):95.04(H)×53.856(V)

13)     Overall Dimension of LCD(mm):105.5(W)×67.2(H)×3.6(D)

14)     Actuation board size(mm):90(W)×48(H)×6.8(D)

15)     Operating Temperature: -20~+70 °C

16)     Relative Humidity:5~95% RH

17)     Storage Temperature: -30~+80°C

18)     Customize: Free for customer ordering starting LOGO, accepts order the CABLE lines

19)     Packing: 60pcs/Box
