Home > Products > Revolving Door > automatic revolving system
automatic revolving system
- 100 Set / Sets per Month
- Shanghai
- T/T D/P D/A Credit Card
Product Details
Place of Origin: | Shanghai, China | Brand Name: | PAD | Model Number: | PARD |
Position: | Commercial | Type: | Revolving Doors | Door Material: | Glass |
Screen Netting Material: | Stainless Steel | Feature: | Folding Screen | Sliding Door Type: | Folding Doors |
Product Description
automatic revolving system
Features:
1. Colorful and central exhibition booth.
2.The door wings can be folded.
3.Elegant and grand view.
4.Digital control panel.
5.Durable servo motor.
6.Wide passage
Components:
1.surface decoration(optional): A.Stainless steel 304, 1.0mm or 1.2mm.
B.Copper 1.0mm
C.Florine-carbon painting
D.Oxidation
2.Structure: extruded 6063-T5 alluminum frame.
3.Revolving panel: 6mm tempered glass
4.Exhibition booth: Alluminum alloy or stainless steel
5.Curving glass: 6mm+6mm laminated glass or 12mm tempered bending glass or specially required glass.
6.Radial Ceiling plates: A.Alluminum alloy
B.Copper
C.Stainless steel
7.Switch: A.Disabled button
B.Emergency button.
8.Sensor: A.Trigering sensor
B.Anti-clamp sensor
C.safety light curtains
9.Light:cold light lamp
Technical parameters:
1.Power supply: 50HZ, 220V
2.Servo motor: 180W
3.Light: 270W
4.Speed:1-4 RPM( manual or auto adjustable)
5.Noise: <42db
6.Torque:<2nm
inner diameter | external diameter | Canopy Height | door Wing Height | Entrance & Exit Width | |
3-Wing | 4-Wing | ||||
3000 | 3180 | 300 | 2200 | 1400 | 2030 |
3200 | 3380 | 300 | 2200 | 1500 | 2170 |
3400 | 3580 | 300 | 2200 | 1600 | 2310 |
3600 | 3780 | 300 | 2200 | 1700 | 2450 |
3800 | 3980 | 300 | 2200 | 1800 | 2590 |
4000 | 4180 | 300 | 2200 | 1900 | 2730 |
4200 | 4380 | 300 | 2200 | 2000 | 2870 |
4800 | 4980 | 300 | 2200 | 2300 | 3050 |
unit:mm |
