FCST02106 FTTH Indoor Fiber Optic Function Of Terminal Box, fiber optic distribution box, Fiber Box, fiber optical joint box
Description:
1.1 Wall outlet is meant for welding the installation Optical cable to pigtails at the customer’s place.
1.2 The wall outlet must be wall mounted. If the cable is installed on the wall, the cable entry is placed into the wall outlet from the upper right side. If the cable is installed under the wall, cable entry is placed into the wall outlet from the back side
1.3 The wall outlet consists of the base, splice cassette, and cover.
1.4 The base is screwed on the wall and it serves as the optical installation cable entry and fixation of Optical adapters SC/UPC Dx(duplex)and running patch-cords
1.5 Splice cassette consists of excess lengths of optical cables and heat shrink fusion protectors(2pcs)
1.6 The cover serves to protect the contents of the wall outlet
1.7 Wall outlet is constructed in such a way that it assures a minimal bending radius of optical cables
1.8 Rmin=30mm and that it prevents the switch-off of the connector of the patch cord without the removed cover
1.9 The material of Wall outlet is the ABS in white colour.
2. Optical adapter SC/UPC Dx(blue-duplex)with ceramic sleeve -1 piece
3. Pigtail SC/UPC L=1m O.D.=0.9mm protection-2 piece
Fiber 9/125SM ITU-Tg.652.d.IL 0.3dB;RL=-50dB
Specification:
ProductNo. |
Dimension |
Weight |
Function |
FCST02106 |
205x120x38(mm) |
210g |
1 pc SC duplex adaptor |
- Packing: By carton
- Shipping: BY AIR, BY SEA,BY TNT,BY DHL,BY FEDEX.
OEM,FTTH consultant, after--sale service,Micro cable Solution consultant(design).
- Principle: Professional; Accurate; Prompt; Reliable.
- Manufacturing Capacity:10000 pieces/week.
- Equipment:Injection molding machine;Punching machine;Guillotine Shear;CNC punching machine; CNC bending machine;
- Exhibition: ECOC,OFC, Local Exhibition.
- R & D department:System Engineer; Technical Support Engineer; Communication Engineer; Test Engineer.;Data-Base Administrator;Program Engineer;
- Partner: China Mobile.HuaWei. China Telecom.ZTE.Tyco,3M.
- Market: Europe, South American,North American,Asia,South Africa.
- Payment item:L/C,T/T,Western Union,Paypal.
- Transaction item:FOB,C&F,CIF,EXW.
