Product Name: screen printing mesh
Specification:
Mesh count |
Thread diameter(um) |
Mesh opening(um) |
Open Area(%) |
Thickness(mm) |
Theoretic Ink Volume (cm3/m2) |
32T |
55 |
263 |
68 |
95+/-6 |
64.6 |
40T |
55 |
199 |
61 |
95+/-6 |
58.0 |
47T |
55 |
157 |
55 |
95+/-6 |
55.1 |
53T |
55 |
133 |
50 |
90+/-6 |
45.0 |
59T |
55 |
114 |
46 |
100+/-6 |
46.0 |
63T |
55 |
101 |
42 |
108+/-7 |
45.4 |
80T |
48 |
77 |
38 |
89+/-5 |
33.8 |
100T |
40 |
60 |
36 |
76+/-4 |
27.4 |
120T |
34 |
49 |
35 |
60+/-3 |
21.0 |
140T |
34 |
38 |
20 |
60+/-3 |
16.8 |
150T |
30 |
31 |
23 |
51+/-1 |
12.0 |
165T |
30 |
30 |
25 |
60+/-3 |
15.0 |
180T |
45 |
92 |
40 |
68+/-8 |
27.6 |
280T |
40 |
43 |
26 |
78+/-7 |
18.0 |
305T |
40 |
49 |
21 |
50+/-5 |
19.5 |
Details Photo:
By the way, my friend, We could do below product. click it to see more...
Application:
SilkScreen Printing Mesh is woven from yarn that is extruded from heated polyester into a single strand. Widely used in textile printing, plate making printing, electronic printing, ceramics, glass, stained paper printing, label plate, and advertising.Also widely used in fitering.
Features :
1. Faster turnaround time from the screen room to the pressroom
2. Good diathermancy
3. High air permeability
4. Acid resistance and Alkali resistance
5. Long working life
6. Hard wear
7. Imported weaving machines from Switzerland and Italy
About belt package, Normally we pack one roll into the strong woven bag. and then put them into big carton.The complete package is like below image, it is very safe when ship by sea or by air.
Below are images of our manufacturing factory. Due to space be limited, only show part of picutres from our maufacturing factory, if you come to China, Welcome you to visit us !
If any questions, Welcome to inquiry us, my friend, will reply to you within 24 hours ! We value every order, even if one roll. Accept the custom service.
