Solar Water Heater Project For South Africa

Name: Solar Water Heater Project For South Africa
Brand: GAODELE
SKU: 134309491
Availability: InStock

US$ 245 - 500 MOQ: 1 Set

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

GAODELE

Model Number:

GDL-SP58-1800-10000

Zhejiang Gaodele New Energy Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name GAODELE

Model Number GDL-SP58-1800-10000

Type Manifold Collector

Application Solar Thermal

Pipe Material Glass

Specifications

1.supply hot water for big project ;
2.good design and low price;
3.10- 15 days a container ;
4.CE,CC ;
5.long life span.

Solar Water Heater Project For South Africa

solar collector Material and Features:

solar collector Tank	Inner Tank Thickness	1.5 mm/1.8mm/2.0mm
	Outer Tank Thickness	0.5 collector mm
	Inner Tank Material	SS 304
	Outer Tank Material	Galvanized steel/Stainless steel
	Color	According to customers'
Solar collector Bracket	Bracket Material	Galvanized steel Powder Coated
	Thickness	1.2mm
	Color	According to customers'
Solar collector Reflector	Material	stainless steel/Aluminium Alloy
Solar collector Reflector	Type	Strip Type
Solar collector Insulation	Material	PUF
Solar collector Insulation	Thickness	50 mm
Solar collector Capacity	100,150,200,250,300,400,500 Liters
Solar collector Warranty	5 years

Vacuum Tube Material and Features:

Tube structure		All-glass double-tube co-axial structure
Glass material		Borosilicate 3.3glass
Outer tube diameter and glass thickness		Φ =47± 0.7mm & T=1.6mm ± 0.15mm
Outer tube diameter and glass thickness		Φ =58± 0.7mm & T=1.6mm ± 0.15mm
Inter tube diameter and glass thickness		Φ =37± 0.7mm & T=1.6mm ± 0.15mm
Inter tube diameter and glass thickness		Φ =47± 0.7mm & T=1.6mm ± 0.15mm
Tube length		1500mm, 1800mm
	Coating material	AL-N/SS/Cu
Absorber coating	Sediment method	Three Targets magnetron sputtering plating
	Absorption	a: ≥92%(AM1.5)
	Emittance	ε ≤ 3.4% (80° C± 5° C)
Vacuum degree		P ≤ 5.0× 10 -3 Pa
Hail resistance		Φ 25 mm
Pressure-endure		0.8 Mpa
Temperature-endure		250° C
Life		> 15 years
