Specifications
lar collector2.best quality solar collector manufacturer
urized solar collector
4.low price solar collector
100% Clean Energy All Glass Vacuum Tube Solar Water Heater with Heat Pipe in the Vacuum Tube
solar collector Material and Features:
| solar collector Tank | Inner Tank Thickness | 1.5 mm/1.8mm/2.0mm |
| Outer Tank Thickness | 0.5 collector mm | |
| Inner Tank Material | SS 304 | |
| Outer Tank Material | Galvanized steel/Stainless steel | |
| Color | According to customers' | |
| Solar collector Bracket | Bracket Material | Galvanized steel Powder Coated |
| Thickness | 1.2mm | |
| Color | According to customers' | |
| Solar collector Reflector | Material | stainless steel/Aluminium Alloy |
| Type | Strip Type | |
| Solar collector Insulation | Material | PUF |
| Thickness | 50 mm | |
| Solar collector Capacity | 100,150,200,250,300,400,500 Liters | |
| Solar collector Warranty | 5 years | |
solar collector vacuum tube Material and Features:
| Tube structure | All-glass double-tube co-axial structure | |
| Glass material | Borosilicate 3.3glass | |
| Outer tube diameter and glass thickness | Φ =47± 0.7mm & T=1.6mm ± 0.15mm | |
| Φ =58± 0.7mm & T=1.6mm ± 0.15mm | ||
| Inter tube diameter and glass thickness | Φ =37± 0.7mm & T=1.6mm ± 0.15mm | |
| Φ =47± 0.7mm & T=1.6mm ± 0.15mm | ||
| Tube length | 1500mm, 1800mm | |
| Coating material | AL-N/SS/Cu | |
| Absorber coating | Sediment method | Three Targets magnetron sputtering plating |
| Absorption | a: ≥92%(AM1.5) | |
| Emittance | ε ≤ 3.4% (80° C± 5° C) | |
| Vacuum degree | P ≤ 5.0× 10 -3 Pa | |
| Hail resistance | Φ 25 mm | |
| Pressure-endure | 0.8 Mpa | |
| Temperature-endure | 250° C | |
| Life | > 15 years | |
solar collector Working Principle:
solar collector Details Pictures:
solar collector Loading Ability:
| Model | Vacuum Tube | Tank | Loading Qty | |||
| Size /mm | No | Capacity/L | 20GP | 40GP | 40HQ | |
| GDL-SP58-1800-12 | 58×1800 | 12 | 120 | 150 | 313 | 367 |
| GDL-SP58-1800-15 | 58×1800 | 15 | 150 | 129 | 267 | 313 |
| GDL-SP58-1800-18 | 58×1800 | 18 | 180 | 108 | 223 | 261 |
| GDL-SP58-1800-20 | 58×1800 | 20 | 200 | 99 | 205 | 240 |
| GDL-SP58-1800-24 | 58×1800 | 24 | 240 | 90 | 187 | 219 |
| GDL-SP58-1800-30 | 58×1800 | 30 | 300 | 75 | 155 | 181 |
solar collector Thickness Measure and Argon Welding
solar collector Main Production Line
solar collector Quality Control
solar collector Certificates
Solar collector Exhibition
