OEM Professional Speaker For Amplifier

OEM Professional Speaker For Amplifier thumbnail-1
OEM Professional Speaker For Amplifier thumbnail-2
OEM Professional Speaker For Amplifier thumbnail-3
OEM Professional Speaker For Amplifier thumbnail-4
OEM Professional Speaker For Amplifier thumbnail-5
OEM Professional Speaker For Amplifier thumbnail-6
OEM Professional Speaker For Amplifier photo-1
OEM Professional Speaker For Amplifier photo-2
OEM Professional Speaker For Amplifier photo-3
OEM Professional Speaker For Amplifier photo-4
OEM Professional Speaker For Amplifier photo-5
OEM Professional Speaker For Amplifier photo-6
US$ 1 - 999 MOQ: 1 Carton
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
QQ CHINAPA, Lingba, QQCHINAPA
Model Number:
H-10
Contact Supplier Request Quote Chat Now
Guangzhou Lingyin Electronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
guanzghou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name QQ CHINAPA, Lingba, QQCHINAPA
Model Number H-10
Product Description

Main Function Description:

 1*2-Way,2-frequency,full range with high sound pressure and sensitivity,

 2*With wide directive angle:90*55 degree,make sure that the sound reinforcement ability of the loudspeaker can be covered a wide area,

 3*Compatible with imported UKM paper cone,

 4*An computer optimization simulation design to realize good frequence response & phase feature, 5*Easy and convenient to install,

 6*It's widely applied in full range amplifier system,bars,ballroom,audio show amplifier system,Hall PA,flowing performance and supporting large-scale sound reinforcement system fills,

 7*It can be used as replaying appliance for hign quality output,along with a low frequency speaker.(recommended 350W-1000W)

Model
H-10
H-12
H-15
System
2-WAY FULL RANGE
2-WAY FULL RANGE
2-WAY FULL RANGE
Frequency response
55HZ-18KHZ
55HZ-18KHZ
55HZ-18KHZ
Driver
LF:10’*1HF:1’*1
LF:12’*1HF:1’*1
LF:15’*1HF:1’*1
Nominal impedance
8Ω
8Ω
8Ω
Sensitivity
97db
97db
98db
Rated power
250W
350W
500W
Maximum
123db
123db
125db
Size(mm)
300*303*503
360*400*605
410*463*685
Weight
17.5
26
38

Main Function Description:

 1*2-Way,2-frequency,full range with high sound pressure and sensitivity,

 2*With wide directive angle:90*55 degree,make sure that the sound reinforcement ability of the loudspeaker can be covered a wide area,

 3*Compatible with imported UKM paper cone,

 4*An computer optimization simulation design to realize good frequence response & phase feature,

 5*Easy and convenient to install,

 6*It's widely applied in full range amplifier system,bars,ballroom,audio show amplifier system,Hall PA,flowing performance and supporting large-scale sound reinforcement system fills,

 7*It can be used as replaying appliance for hign quality output,along with a low frequency speaker.(recommended 350W-1000W)

Model
F-10
F-12
F-15
F-215
System
2-WAY FULL RANGE
2-WAY FULL RANGE
2-WAY FULL RANGE
2-WAY FULL RANGE
Frequency response
60HZ-18KHZ
55HZ-18KHZ
55HZ-18KHZ
40HZ-18KHZ
Driver
LF:10’*1HF:1’*1
LF:12’*1HF:1’*1
LF:15’*1HF:1’*1
LF:15’*1HF:1.5’*1
Nominal impedance
8Ω
8Ω
8Ω
4Ω
Sensitivity
95db
97db
97db
98db
Rated power
250W
300W
350W
700W
Maximum
121db
123db
123db
125db
Size(mm)
400*385*620
470*440*660
545*525*780
630*590*1180
Weight
18.5
26
32.5
38

Main Function Description:

 1*2-Way,2-frequency,full range with high sound pressure and sensitivity,

 2*With wide directive angle:90*45 degree,make sure that the sound reinforcement ability of the loudspeaker can be covered a wide area,

 3*An computer optimization simulation design to realize good frequence response & phase feature, 4*Easy and convenient to install,

 5*It's widely applied in full range amplifier system,bars,ballroom,audio show amplifier system,Hall PA,flowing performance and supporting large-scale sound reinforcement system fills,

 6*It can be used as replaying appliance for hign quality output,along with a low frequency speaker.(recommended 350W-1000W)

Model
SRX-712
SRX-715
SRX-7215
System
12’,LF cone driver
15’,LF cone driver
2*15’,LF cone driver
3’ HF compression driver(horm-load)
3’ HF compression driver(horm-load)
3’ HF compression driver(horm-load)
Frequency response
55HZ-19KHZ
55HZ-19KHZ
40HZ-19KHZ
Coverage angle
90 ºH×45 ºV
90 ºH×45 ºV
90 ºH×45 ºV
Axial sensitivity
97db
99db
103db
Calculated output
136db
136db
137db
Nominal impedance
8Ω
8Ω
4Ω
Rated power
400W(rated power AES)
550W(rated power AES)
1000W(rated power AES)
1600W(Pead power)
2000W(Pead power)
4000W(Pead power)
Enclosure material
Plywood
Plywood
Plywood
Cabinet finish
Textured black polyester paint
Textured black polyester paint
Textured black polyester paint
Connectors
＋1/﹣1, ﹢2/﹣2
＋1/﹣1, ﹢2/﹣2
＋1/﹣1, ﹢2/﹣2
Size(mm)
550*350*350
440*720*410
535*1200*510
Weight(kg)
26
34
62
Model
S-12
S-15
S-18
S-218
System
SUB BASS
SUB BASS
SUB BASS
SUB BASS
Frequency response
55HZ-400KHZ
45HZ-400KHZ
35HZ-400KHZ
35HZ-400KHZ
Driver
LF:12’*1
LF:15’*1
LF:18’*1
LF:18’*1
Nominal impedance
8Ω
8Ω
8Ω
4Ω
Sensitivity
97db
101db
97db
97db
Rated power
300W
350W
450W
900W
Maximum
123db
127db
123db
127db
Size(mm)
400*500*550
470*500*690
560*600*690
1065*780*560
Weight
27
32
42
82
