360mW RG Five lens dmx beam disco laser lighting

Model Names

L2650

Description

360mW RG Five Lens Laser Light

Feature

This five tunnel laser light has many pre-programmed stunning effects with over 100 laser patterns and over 300 laser effects, such as wave, tunnel, circle, dots, fan shaped, etc. Laser beams can be shown one by one from five apertures, or scan separately towards different direction on systematic procedure. Five pairs of X/Y high-speed step motors are working simultaneously to make the beams very smoothly, mellow and full, to cover the stage at 120°. In Sound Active mode, this laser light is "Black Out" when there is no music. In Master/Slave mode, up to 32 same units can link together without control. Attractive appearance is designed to make people love this laser light.

Scanning

Micro-step motor scanning at big angle

Laser

Red: 100mW+100mW+100mW 650nm DPSS laser

Green: 30mW+30mW  532nm DPSS laser

Total 2pcs Green diodes and 3pcs red diodes.

Total power: 1200mW

Play Mode

Sound Active, AUTO, Master/Slave

DMX channel: 1 channel control with the function of BLACK OUT

                          (this laser light does NOT support DMX control)

Interface

3 pins XLR jack for DMX or Maser-Slave linking

Power Supply

110V or 220V-250V, 50/60HZ, 50W

Net Weight

7.6Kg

Gross Weight

8.6Kg (inner box), 18.6Kg (outer box)

Volume Weight

11.1Kg (/5000) or 9.3Kg(/6000), each inner box

24.7Kg (/5000) or 20.6Kg(/6000), each outer box

Inner Box

930*264*176(0.043m³)

Outer Box

956*280*392(0.106m³), 2pcs/carton

Accessories

Included: User’s Manual

Power Supply Cable (UK, USA, EURO, AUS, BRZ).

Applicable Place

DJs, Bands, Bars, Pubs, Clubs, KTV, Family party, etc.

Customized

OEM, ODM
