Entertainment Lighting RGB Moving Head Laser Stage Lighting

Model Names

LH180RGB

Description

entertainment lighting RGB moving head laser stage lighting

Feature

This moving-head animation laser light is a great achievement on this decade. It has been pre-programmed with 103 kinds of geometric figures and 10 kinds of animations. All those patterns can be operated under DMX control, which has functions of moving up/down/left/right, zoom in/out, rotating, drawing, billowing, speed, color, etc. The most advance function is the horizontal/vertical speed control, which has 256 levels on the speed. On the easy-to-use LCD indicator, this laser light can be set to the stay-still mode. Horizontal angle at 0 to 540°and vertical angle at 0 to 270°. Each level on horizontal angle is 2.1° and on vertical angle is 1.05°.

Scanner

25kpss High-speed optical scanner, big angle scanning (0 to 30°)

Optional 30K, 40K, 50K

Horizontal moving angle:

540°

Vertical moving angle:

270°

Scanning

Tilt and Pan

Vertual Operating platform:

LCD1602 indicator and 4-in-1 key control, easy to use

Laser

Green: 300mW 532nm
Red:  1000mW 650nm

Blue:  500mW 450nm

Mixed white laser 1800Mw

1.8W RGB Multi Color laser

Play Mode

Sound Active, AUTO-Beam, AUTO-Animation, DMX, Master/ Slave, PC Control

DMX channels: 15

PC Control

Compatible ILDA laser show software with ILDA interface. Use electronic switches to conversion full ILDA signal

Safety Capacity

Design according to security and good performance, safer to human and environment. Master/Slave mode, DMX512 mode and PC Control mode, will shut off laser automatically without trigger signal

Power Supply

Bi-Voltage 110V to 220V-250V, 50/60HZ, 50W

Net Weight

9.5Kg

Gross Weight

12Kg (in carton box)

29Kg (in Flight case)

Volume Weight

Kg (/5000) or Kg(/6000)

Kg (/5000) or Kg(/6000), with flightcase

Inner Box

600*430*400(0.11m³), with flightcase

Outer Box

1pcs/carton

Accessories

Included: User’s Manual

Power Supply Cable (UK, USA, EURO, AUS, BRZ).

Optional: DMX cable

                 DB25 ILDA/PC Cable

                 Flight case

                 Laser software, such as Quickshow, LD2000, iShow, Mamba Black, Phoenix, or others.

Applicable Place

Logo, company advertising, superstar fashion show, DJs, Bands, Bars, Pubs, Clubs, Roller skating rinks, KTV, Family party, etc.

Customized

OEM, ODM
