7000kw 6kv Medium Voltage Frequency Converter Ac/ac Converter

7000kw 6kv Medium Voltage Frequency Converter Ac/ac Converter thumbnail-1
7000kw 6kv Medium Voltage Frequency Converter Ac/ac Converter thumbnail-2
7000kw 6kv Medium Voltage Frequency Converter Ac/ac Converter photo-1
7000kw 6kv Medium Voltage Frequency Converter Ac/ac Converter photo-2
US$ 40,000 - 500,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
AUBO
Model Number:
AMV-IV06-7000
Contact Supplier Request Quote Chat Now
Nanjing Aubo Electric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name AUBO
Model Number AMV-IV06-7000

  7000kw 6kv Medium Voltage frequency converter  ac/ac converter



Product Description



 AMVI inverter is a high tech product with our own intellectual property rights and good performance, for the speed control of 3kv / 6kv/10kv medium voltage motor.

The advantage:

  • Perfect output waveform, harmonics free
  • High power factor, high efficiency
  • Motor speed control & soft start enabled
  • Reduce operation and maintenance cost
  • Easy operation
  • Perfect protection and auto-diagnosis for fault7000kw 6kv Medium Voltage frequency converter ac/ac converter

    Typical Application





    Thermal powerindustry: induced draft fan, blower, dust collection fan, compressor, sewage pump, boiler feed pump etc.

    Petrochemical industry: main pumps, submersible pumps, injection pumps, circulating pump, boiler feed pump, halogen water pump, fan, descaling pump, mixer, gas compressors, extrusion machine, etc Mining and metallurgy: slurry pump, induced draft fan, blower,, dust removal fan, descaling pump, centrifugal feed pump, etc Cement manufacturing: water pump, boiler feed pump, halogen water pump, fan, descaling pump, mixer, gas compressors, induced draft fan, preheat tower fan,

    pressure blower fan, cooler dust cleaning fan, ball mill for raw material, kiln gas fan, cooler exhausting fan, classifier fan, the main dust collection fan, etc Water supply and wastewater treatment: main line pumps, submersible pumps, injection pumps, circulation pump, sewage pump, cleaning pump, biological processing tower pump Other industry: pulp beater, pumps, rotating machinery, wind turbines, wind tunnel, etc 7000kw 6kv Medium Voltage frequency converter ac/ac converter



      7000kw 6kv Medium Voltage frequency converter  ac/ac converter

  • Medium voltage frequency converter

  •

    Model Rated Current(A) Rated Power(KW) Model Rated Current(A) Rated Power(KW)
    AMV-IV06-200 26 200 AMV-IV10-0220 17 200
    AMV-IV06-250 30 250 AMV-IV10-0250 19 250
    AMV-IV06-280 33 280 AMV-IV10-0280 21 280
    AMV-IV06-315 37 315 AMV-IV10-0315 24 315
    AMV-IV06-355 42 355 AMV-IV10-0355 27 355
    AMV-IV06-400 48 400 AMV-IV10-0400 30 400
    AMV-IV06-450 54 450 AMV-IV10-0450 33 450
    AMV-IV06-500 60 500 AMV-IV10-0500 37 500
    AMV-IV06-560 67 560 AMV-IV10-0560 41 560
    AMV-IV06-630 75 630 AMV-IV10-0630 46 630
    AMV-IV06-710 84 710 AMV-IV10-0710 51 710
    AMV-IV06-800 95 800 AMV-IV10-0800 57 800
    AMV-IV06-900 106 900 AMV-IV10-0900 64 900
    AMV-IV06-1000 118 1000 AMV-IV10-1000 71 1000
    AMV-IV06-1120 132 1120 AMV-IV10-1120 79 1120
    AMV-IV06-1250 146 1250 AMV-IV10-1250 88 1250
    AMV-IV06-1400 164 1400 AMV-IV10-1400 98 1400
    AMV-IV06-1600 185 1600 AMV-IV10-1600 112 1600
    AMV-IV06-1800 220 1800 AMV-IV10-1800 127 1800
    AMV-IV06-2000 229 2000 AMV-IV10-2000 141 2000
    AMV-IV06-2240 251 2240 AMV-IV10-2250 157 2250
    AMV-IV06-2500 281 2500 AMV-IV10-2500 175 2500
    AMV-IV06-2800 324 2800 AMV-IV10-2800 295 2800
    AMV-IV06-3150 363 3150 AMV-IV10-3150 230 3150
    AMV-IV06-3550 428 3550 AMV-IV10-3550 259 3550
    AMV-IV06-4000 482 4000 AMV-IV10-4000 290 4000
    AMV-IV06-4500 542 4500 AMV-IV10-4500 326 4500
    AMV-IV06-5000 602 5000 AMV-IV10-5000 362 5000
    AMV-IV06-6000 723 6000 AMV-IV10-5600 405 5600
    AMV-IV06-7000 844 7000 AMV-IV10-6300 455 6300
    AMV-IV06-8000 964 8000 AMV-IV10-7100 512 7100







Our Service

1,We can design the job for your specs or your project

2,We provide site commissioning on demand





Packaging

7000kw 6kv Medium Voltage frequency converter ac/ac converter





shipping

We have several transport options for customer to choose:



1, Transport by sea



2, Transport by  truck



3, Transport by train



4, Transport by express service



5. Transport by air,  (to be confirmed )





Certifications

7000kw 6kv Medium Voltage frequency converter ac/ac converter7000kw 6kv Medium Voltage frequency converter ac/ac converter7000kw 6kv Medium Voltage frequency converter ac/ac converter
