Specifications
refrigerant: R22 or R407crotary compressor
air conditioner accessories
window air conditioner compressor r410a
Rotary hermetic compressors use the rotating action of a roller inside a cylinder to compress the refrigerant. Rotaries, by design, include less parts than other types of compression technology and provide an alternative, efficient option for various applications.
High efficiency BOYARD rotary compressors provide enhanced reliability, reduced sound and maximum flexibility with vertical and horizontal installation options for air conditioning and refrigeration applications.
Today’s modern air conditioning and commercial refrigeration applications require high efficiency combined with the ability to utilize more eco-friendly refrigerants. BOYARD rotary compressors continue to lead the way.
performance parameters:
| Refrigerant | Model | Power Supply | Cylinder Volume cm³ | Refrigerating Capacity | Input Power | COP | RUN CAPACITOR(µF/450V) | ||
| W | Btu/h | W | (W/W) | ||||||
| VERTICAL | R22 | JVR075K* | 220-240V/50Hz | 7.5 | 1275 | 4348 | 405 | 3.15 | 15 |
| JVR092K* | 220-240V/50Hz | 9.2 | 1565 | 5337 | 495 | 3.15 | 20 | ||
| JVR132K* | 220-240V/50Hz | 13.2 | 2244 | 7652 | 712 | 3.15 | 20 | ||
| KVR149K* | 220-240V/50Hz | 14.9 | 2520 | 8593 | 800 | 3.15 | 25 | ||
| KVR164K* | 220-240V/50Hz | 16.4 | 2770 | 9446 | 880 | 3.15 | 25 | ||
| KVR192K* | 220-240V/50Hz | 19.2 | 3200 | 10912 | 1010 | 3.15 | 30 | ||
| KVR208K* | 220-240V/50Hz | 20.8 | 3535 | 12054 | 1120 | 3.15 | 30 | ||
| SVR236K* | 220-240V/50Hz | 23.6 | 3955 | 13487 | 1255 | 3.15 | 35 | ||
| R410A | KVA096K 2FN | 220-240V/50Hz | 9.6 | 2250 | 7681 | 800 | 2.80 | 25 | |
| SVA135K 4DN | 220-240V/50Hz | 13.5 | 3190 | 10890 | 1120 | 2.85 | 30 | ||
| R134a | KVB096K 1FT | 220-240V/50Hz | 9.6 | 1100 | 3740 | 370 | 2.95 | 15 | |
| KVB135K 1FT | 220-240V/50Hz | 13.5 | 1500 | 5100 | 490 | 3.06 | 20 | ||
| SVB254T 2DN | 115V/60Hz | 25.4 | 3500 | 11900 | 1185 | 2.95 | 50 | ||
| * In developing. (The displacement could be adjusted or developed as your requirement.) | |||||||||
Application:
air conditioner
dehumidifier
industrial water chillers
sample service: could try sample firstly(Most models are in stock)
customized service: R&D as your requirement
After-sales service: With the technical support
Management system: ISO 9001
Production capacity: 20,000/Week
QC: CCC, CE, RoHS, REACH
Designed and developed: Have R&D Term
Export market: global (mainly for Europe, Middle East, America, SouthEast, etc.)
Exhibition Experience
1. Where is your company located in?
Located in Shuguang Road, Lanxi City, Zhejiang Province, China.
2. What's your delivery time?
25days for cargo; 5days for sample after payment or deposit.
3. What's your shipping port?
Ningbo or Shanghai Port.
4. What's your MOQ?
Could start as sample firstly, to match the application.
5. What's the payment terms?
T/T, L/C, ESCROW
6. How could do the payment?
T/T, ESCROW
7. What you supply?
- R22, R407C rotary air conditioner compressor
- R134a, R410a rotary compressor
- R134a DC 12V 24V 48V 72V compressor
- R22, R404a refrigeration compressor
- R22, R404a condensing unit
- R134a refrigerator compressor
8. Could you do the New products R&D service for me?
Any products of HVAC & refrigeration, we could do the R&D for you.
