HT6620 series Hot model FS tech hotel door locks, open hotel lock, computer control hotel locks.
Buy door locks description:
1. Zinc alloy material board.
2. Inside lining rust prevention steel plate.
3. Structure of five tongue America standard.
4.16 bit processor, the program efficiency is higher.
5. M1/T57/EM4100 many kinds of cards to be choosing.
6. Suitable for hotel, luxurious villa, apartment, intelligent building place and so on.
Buy door locks advantages & features:
1. Zinc alloy panel, magnificent appearance.
2. Two unlocking patterns: mechanical key and RF card.
3, Easy to install, no-disturbing mode, top safety.
4. Side battery, easy to change, long service life.
5. Battery box is connected with the lock body into a whole set.
6. The motor has high quality, low power dissipation.
7. Our PCB is imported material from Taiwan.
8.9V Emergency battery; Musical buzzer; Backup mechanical key.
9. Sound and Light Prompt for all operations.
10.Safe Handle design to protect any break-in attempt.
Buy door locks technical parameters :
Type |
HT6620G-MF |
Voltage range |
4.5-6.5 V |
Static Power consumption |
< 30 uA |
Dynamic power consumption |
< 200 mA |
Single operation |
0.8 seconds |
Card read time |
< 0.4 S |
Card Types |
M1 Card |
Card Life |
10 years |
Install door thick |
38-55 mm |
Facial color |
Golden |
Drawing card read distance |
25MM |
Buy door locks System Composition:
Normally this system is composed of the bellowing parts:
1. Lock (qty = guest room)---For open the door
2. Card Encoder (1pcs/hotel) ---For issuing all kinds of cards
3. Energy Saving Switch (qty = guest room)---To get the power
4. Cards -----For open the lock
5. Data collector (1pcs/hotel, optional by customers)---For getting the time and times of the
entrance information from the lock
6. Self developed software (1 disk, free of charge)---For setting the program the whole system.
Buy door locks installtion drawing:
Buy door locks more detail:
Buy door locks door open directions:
Buy door locks series:
Payment:
If the total amount is less than 500USD, we prefer to accept Paypal or Western Union.
For big amount we accept bank transfer.
Shipment:
Normally we will use UPS, DHL, FEDEX or EMS express. It usually takes 3-7 working
days depending on the countries deliver to. We can also arrange other shipment way per
your requirement and instruction, such as sea shipment, air shipment, etc.
Warranty:
Warranty for one year, maintenance forever, change within 3 months because of product
quality.
