Specifications
1.Magnetic2.indicator and signal out-put
3.Pure Iron lock cylinder and copper coil
4.No residual magnetism
5.Chrome finish
The working principle of electro magnetic lock is that when power on the lock will generate electromagnetictism to
absorb the mount plate to lock the door. It is fail safe maglock. Power on to lock and power off to unlock.
Electromagnetic lock can be installed by two ways,hanging installation and flushing installation.
Product |
Single door electromagnetic lock |
Lock Dimension |
250*48*28(mm) |
Armature Plate Dimension |
182L*46W*13H(mm) |
Input Voltage |
DC12V±10%or DC24V±10% |
Holding Force |
350KG(800LBS) |
Current |
12V/350mA 24V/180mA |
Operating temp |
-10~+55°c(14-131F) |
Suitable Humidity |
0-95%(non-condensing) |
Lock Finish |
Chrome plating |
Cover Finish |
Drawing oxidation |
Safety Type |
Fail Safe |
Suitable |
Wooden door, Glass door, Metal door, Sliding door. |
