LED Panels, LED All in One Teaching Interactive Whiteboard
US$ 1,000 - 1,300
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
IEBOARD or OEM
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Interactive Touch PanelNegotiableMOQ: 1 Set -
LED Multi Touch Screen Monitor, Touch Screen Led Tv, LED Interactive WhiteboardUS$ 2,300 - 2,350MOQ: 10 Pieces
-
IR LED Multi Touch Screen,LED Monitor,dual Touch FrameUS$ 2,300 - 2,350MOQ: 5 Pieces
-
IR LED Multi Touch Screen,dual Touch Frame,sizesUS$ 99 - 150MOQ: 5 Pieces
-
IEBOARD TL Series All in One Touch TV [Gary's Edition]NegotiableMOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
IEBOARD or OEM
Specifications
1, A+ screen,more helpful to protect eyes2,high reliable, long time to use
3.writting smoothly and react quickly
| IEBOARD LED interactive whiteboard specification | |||||||
| Model | DS-9065IH | ||||||
| Image | |
||||||
| LED | Screen size | 65" | |||||
| LED brand: | AUO | ||||||
| External size | 1558*928*107mm(without base) | ||||||
| Size & Weight | Touch size(mm) | 1428.5*803.5 | |||||
| Plywood carton size(mm) | 1690*270*1180 | ||||||
| Net weight(KG)(±1.5kg) | 90 | ||||||
| Gross weight(KG)(±1.5kg) | 113 | ||||||
| Power | Power | < 200W | |||||
| Standby power | < 1W | ||||||
| Active Display Area: | 1209.6(h)x680.4(v)mm | ||||||
| Pixel Pitch: | 0.630(h)x0.630(v)mm | ||||||
| Display | Display Colors | 1.07 billion colors | |||||
| Number of Pixels | 1920x1080 pixels | ||||||
| Brightness | 500cd/m2 | ||||||
| Viewing Angle | 178 Degree | ||||||
| TV standard: | NTSCM/N,PALBG/DK/I/H,SECAML/L | ||||||
| Multimedia Formats | MPEG1,MPEG2,MPEG4,H264,RM,RMVB,MOV, | ||||||
| USB2.0 Multimedia | Vido/Audio/Picture | ||||||
| USBOnlineSystem Upgrading | Support USB online upgrading function | ||||||
| Resolution | Max. 1080P format | ||||||
| TV | HDMI | V1.3, 720P/1080P | |||||
| Parameters | HDCP | V1.1 | |||||
| 3D DNR | Support 3D video DNR | ||||||
| Scanning Format | Support 1080i 3D Video crisscross DAS (Dynamic Adaptive | ||||||
| SoundControl | Automatic sound standard detection, adjustment | ||||||
| and surround Sound | |||||||
| SoundOutput | 2X10W | ||||||
| USBMultimediaInput port | 6-line | ||||||
| Touchscreen port | 1-line USB2.0 | ||||||
| Input and | HDMI Input port | 3-line | |||||
| output ports | VGA Input port | 1-line | |||||
| PC Audio port | 1-line | ||||||
| UPBRPaudioandvideo input port | 1-line | ||||||
| AV Input port | 1-line | ||||||
| S-VIDEO port | 1-line | ||||||
| SPDIF port | 1-line | ||||||
| Touch Technology | Infrared touch technology | ||||||
| Touch mode | Single, multipoint,Mouse click | ||||||
| Inductive objects | Finger,pen or any other opaque objects | ||||||
| Inductive size | Diameter≥5mm | ||||||
| Resolution | 4096*4096 | ||||||
| 1) First dot(click):8ms, continuously(writing):3ms | |||||||
| Response time | 2) multipoint click:first dot(click):8ms,continuously(writing):8ms | ||||||
| 3) Mouse click:first dot(click):8ms,continuously(writing):8ms | |||||||
| Cursor speed | UP to 300 dots/s;Multipoint,mouse click:125 dot/s | ||||||
| Touch | Operating life | ≥60,000,000 times to click | |||||
| parameters | Power | USB power supply (4.6-5V, DC) | |||||
| Power consumption | ≤1w | ||||||
| Multi-touch operation: | Compatible with windows 7 OS, to achieve the multi-touch | ||||||
| and writing with two points,support win7 gesture recognition | |||||||
| Calibration | no need special software to calibrate, just use Table PC setting | ||||||
| to finish the calibration. | |||||||
| Anti-light decay function | Anti-light decay circuits to prevent the performance,degradation | ||||||
| caused by long working hours | |||||||
| LED Test Software | Supply touch screen LED test software to test the function of | ||||||
| each couple of the LED lights and the drawing functions | |||||||
| Antilight interference | can work properly in direct sunlight condition | ||||||
| Interactiveall-in-one touch monitor | 1set | ||||||
| RemoteControl | TVRemotecontrol | ||||||
| Standard | USBcable | 1.5mUSBcablefortouchmonitor,USB2.0 | |||||
| configuration | VGAcable | 1.5mVGAcable | |||||
| 1.5maudiocable | |||||||
| CD | 1pcs | ||||||
| Penswithoutink | 2pcs | ||||||
| Usermanul | 1pcs | ||||||
| PC | |||||||
| High-Version | |||||||
| Motherboard | Gigabyte INTEL H61 | ||||||
| CPU | INTEL G1610 dual-core | ||||||
| Optional | RAM | DDR II 2G | |||||
| Configuration Hard Disk | 500G | ||||||
| Network Adapter | Onboard Realtek RTL8111D Gigabit Ethernet | ||||||
| Wireless Mouse | Optional | ||||||
| Install Accessories | |||||||
| Wall brackets | Optional | ||||||
