Help Center22" CCTV Monitor
US$ 170 - 185
MOQ: 200 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ODM/OEM
Model Number:
22B72A-V
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen Shekou Yantian port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Guangdong, China
Brand Name
ODM/OEM
Model Number
22B72A-V
| Item | Model | 22B72A-V | |
| Panel | LCD Size | 21.5" | |
| LCD Brand | LG | ||
| Panel Model | LM215WF4-TLG1 | ||
| Light source | LED Backlight | ||
| Resolution | 1920 x 1080 (pixels) | ||
| Brightness (typ)/(min) | 250cd/m² nits (typ.) | ||
| Contrast Ratio(typ) | 1000:1 (typ.) | ||
| Response Time(ms) | 3.7ms (typ.) | ||
| Pixel Pitch | 0.083(H) mm x 0.248(V) mm | ||
| Scan Speed | 60 Hz | ||
| View angle | 170°(H) / 160°(V) | ||
| Life Time | 30,000 hrs (min.) | ||
| Color Saturation(x% NTSC) | 72% | ||
| View area | 476.064 (H)mm x 267.786(V)mm | ||
| Colors | 16.7M | ||
| Interface | CVBS IN | - | |
| VGA IN | *1 | ||
| HDMI IN | *1 | ||
| BNC IN | - | ||
| BNC OUT | - | ||
| PC-AUDIO IN | *1 | ||
| AVI IN (BNC) | *1 | ||
| AV2 IN (RCA) | *1 | ||
| Power | Voltage | 100 V ~ 240 V, 50-60 Hz | |
| Maximum (Watt) | <35W | ||
| Standby (Watt) | ≤0.5W | ||
| Environment | Working Temperature | 0°C ~ 40°C | |
| Storage Temperature | Minus 10°C ~ 55°C | ||
| Storage Humidity | 10% ~ 90% RH Non-Condensing | ||
| Working Humidity | 20% ~ 85% RH Non-Condensing | ||
| Display mode | Standard,soft,user,bright | ||
| Longest use(hours/day) | 18hours | ||
| Lanuage | OSD | English | |
| Structure | Product Size (mm)(W x D x H) | 524.15 * 71.8 * 328.12 mm | |
| Package Size (mm)(W x D x H) | 585 * 120 * 480 mm(Carton) | ||
| N.W | 4.7Kg±0.5 Kg | ||
| G.W | 6Kg±0.5 Kg(Carton) | ||
| Shell material | Plastic | ||
| Shell color | Black | ||
| Frame width(T/B/L/R) | 22.78 / 35.45/ 22.78 / 22.78 mm | ||
| VESA | 4-M4 Screw hole 75mm*75mm | ||
| Packaging / Accessories | Remote control | *1 | |
| Power Cord | *1 | ||
| Base | *1 | ||
| Battery | - | ||
| Wall Bracket (Optional) | *1 | ||
| Qualified certificate lable | *1 | ||
| Instruction Manual | *1 | ||
| Warranty card | *1 | ||
