Specifications
0.85 m * 1.22 m uv led flatbed printerColor: C M Y K W
Pack: 3.0 m * 1.7 m * 1.5 m
12 workdays delivery time
CE Approved
0.85 M * 1.22 m uv led flatbed printer of five color
| Model | WER-EF1310UV |
||
Printing technology |
UV Curing Drop-on-demand Piezoelectric |
||
Max. media size |
0.85 m * 1.22 m |
||
No. of print head |
2 PCS DX5 print head |
||
Color |
5 color Cyan, Magenta, Yellow, Black, White |
||
Ink characteristic |
UV Curing ink |
||
Ink reservoir |
Refillable on the fly while printing |
||
Resolution Options |
360 * 360 dpi, 360 * 540 dpi, 360 * 720 dpi, 720 * 720dpi & 720 *1440 dpi |
||
|
Printing speed |
Standard quality |
30 Square meter/ hour |
|
High quality |
19 Square meter/ hour |
||
Ultra quality |
15 Square meter/ hour |
||
Media type |
Rigid PVC board, ceramic tiles, glass, marble, granite, wood, sheet metal |
||
Print head controls |
Print head temperature and voltage are software adjustable |
||
Print height |
3 mm ~ 8 cm |
|
|
Media handling options |
Sheets to sheets |
||
Drying system |
2 PCS LED lamp |
||
Rip software |
Photoprint 10.0 |
||
Color management |
ICC based color, adjustment curves, density adjustment |
||
File format |
TIFF, JPEG, Postscript 3, EPS, PDF Etc. |
||
Electrical requirements |
50 Hz/ 60 Hz, 220 V(10%) > 20 A |
||
Environmental requirements |
Ambient temperature: 20 - 30°C, Relative humidity: 40 - 70% |
||
Outdoor durability |
5 years |
||
Dimension |
3.0 m * 1.7 m * 1.5 m |
||
Weight |
1500 KGS |
||
Certificate |
CE |
||
Warranty |
One year warranty |
||
Quality plate or label making on rigid materials.
Offer versatile function for professional market like custom made gifts or decoration
Provide fast and cost effective sample making on cardboard or corrugated paper.
UV curing ink features more stable printing, more vivid color ,strong adherence and environmental protection, no odor.
Double linear guider system guarantee the reliable and precise running of carriage.
Adopt imported Japan AC servo motor system for X Y axisto ensure stable performance, durable working and high anti-resistance performance.
Imported quality negative pressure air pump and 4-way valve system guarantee 24 hours no-stop working
and ensure the reliable and durable performance of ink supplying system.
Independent white ink inner cycling system solve the problem to easily generate sedimented.
Intelligent LCD negative pressure system is easy to be adjusted by valve .
Distance between working platform and print-heads can be adjusted from 1mm minimum to 8cm maximum.
TALKING TOM printed on Plastic
