small size multifunctional a3 WER E2000UV printer for mobile phone cover usb golf ball printing ,A3 2000 UV printer
| Printer Model | UV LED A3 WER E2000UV |
| Printing tech | Micro Piezo Technology |
| Nozzle number | 1440 |
| Max print size | 12.95*23.62 inch (329*600mm) |
| Print resolution | 5760*2880 dpi |
| max print thickness | 18cm |
| Print quality | True Photographic quality |
| Printing Direction | Smart Bi-directional Printing Mode |
| Printing speed | 720 dpi 25 seconds/A4 size |
| 1440 dpi 50 seconds/A4 size. | |
| 2880 dpi 110 seconds/A4 size. | |
| Cooling Method | Water cycling cooling system |
| Auto adjustment function | Nozzle automatic detection; print head automatic aligning |
| Applicable industry | Rigid PVC board,phone case , glass, plastic, organic board, leather, rubber, special paper, metal, wood, porcelain, PVC, ABS, acrylic, aluminum, iron sheet, ceramic tile, glass, marble, granite, paperboard etc |
| Operating system | Windows XP/ME/Vista/Win7/MAC |
| Interface | Double USB port |
| Languages | English, Chinese. |
| Ink colors | Dual C, M, Y, K / C, M, Y, K, W, W, W, W. |
| Ink type | UV LED curing ink |
| Lamp type | LED Lamp (saving energy and environmental friendly) |
| Ink system | CISS built inside |
| Height adjustment | Automatic with sensor. |
| Driving power | 110 V/ 220 V. |
| Power consumption | 136 W/ Hour. |
| Ink consumption | 10 ML/SQM. |
| Working environment | 10-35 Celsius |
| Software | Photoshop, CorelDraw, Illustrator, WER RIP, |
| Media feeding system | Auto or Manual |
|
Online video demo of A2 WER-E2000UV Printer: /watch?v=3n0zM2yl0uQ&list=PLRPws9RoMWXOy_4hN5qy3vKnWzIVvSqw0&index=59 |
|
A2 WER-E2000UV Printer: |
|
DX5 Printhead |
| Instruction: DX5, Resolution: 1440DPI | |
| Color: 5 colors | |
| Print mode: 4, 6, 8, 12 Pass | |
| Notes: | |
| A:The Operator need to makeelectrostatic eliminating treatment and wear the Anti-static devices if possible to prevent the high static load from burning the circuit board inside of the printhead. | |
| B: During installation, try not to touch the surface of print head directly. |
| 2000uv Ink Box | |
| introduction: Ink Supply System: CISS | |
| Color: KCMY | |
| Feature: CISS, dustproof,keep in dark place, convenient for ink refill. | |
| Notes: | |
| A: when first filling ink, it will consume part of ink, please check whetherthe ink is enough in time | |
| B: Fill the color ink corresponding with the ink labels, add to 80% of the bottleis enough. |
|
E2000 mainboard |
| Introduction: E2000 original main board | |
| Precautions: | |
| A.try to keeptheaircirculating while using, underdry conditions, in order to avoidtoo much moisturecausinga short circuitboard. | |
| B. Do notattempt to disassemble and weld the parts on the board card | |
| C. Checkthe boardandcable,it mustoperateincase of power off. |
| Platform pulley | |
| Instruction: platform pulley | |
| Functions: connection platform, impetus the translational motion | |
| Precautions: | |
| A.please do not put sundry here; | |
| B.please round to add lubricating oil regularly; |
|
LCD touch screen |
| Instruction:LCD panel | |
| Functions:Used for operating machine starts, platform up and down,foreword and backward | |
| Precautions: | |
| A.Correctly operate the LCD touch screen; | |
| B.you Can't use hard objects to scratch the touch screen; |
| Machine control panel and drive system | |
| Instruction:Platform rising,falling,foreword and backward panel. Platform moving driver and rising driver. | |
| Functions:Used for operating machine starts, platform up and down,foreword and backward | |
| Precautions: | |
| A.The new machine test to check whether all wiring and terminals are connected in good condition or not before use; | |
| B.You are not allowed to remove the control components and circuit board; | |
| C.Replace the board and drive all line should be first tag, prevent the wrong burn out the card and drivers. |
Excellent After-sale Services:
1.One year warranty
You can discuss operation and maintenance with our technician online support service by Skype, MSN etc. Remote control will be provided upon request.
2. Free exchange of new components
Our quality is guaranteed 100%, the spare parts can be replaced within one year free of charge includes the airfreight by express, except for the print head and some consumable parts.
3. Free online consultation
The technician will keep online. No matter what kind of technical questions that you may have, you would get a satisfactory answer from our professional technician easily.
4. Free onsite installation and training
If you are able to help us with getting the visa and also would like to bear the costs involved like flight tickets, food, etc, we can send our technician to your office, and to give you a free installation and training for as long as you know how to operate it
1. What materials can print on ?
POP board, KT board, Acrylic, organic glass etc. The UV printing reduce much work and trouble like lamination, fading, blistering, and save much working hours. Rigid signs board, hard carton or corrugated paper box, special market(like customize and decoration market): glasses, ceramic tiles, wood, even furniture.
2. production capacity / printing speed
Single head uv printer is 60 sec. For A4 size, dual heads uv printer is 30 sec. For A4 size
3. How to move the machines
UV printers belong to precise instrument, when you move them, please turn off all power, remove the cartridges and waste cartridge, keep other parts on the printer, and handle with care, keep shaking and heavy goods away from the printer.
4. How to make 3D embossed texture.
Can through two ways to reach 3D feeling: One is change media, by engrave to reach embossed feeling, then print by WER printers, second is through WER 3D printing technology, to accumulate UV ink to reach 3D effect. The 3D range will be bigger when use first ways; the second way have the height limit, and this way can re-print to reach more 3D effect, e.g. Mountain, use the second way can reach more Layering.
5. How to do when the status of the printhead is not good ?
5.1. Trun off power, move the printhead to the initial position, check if the printhead and cap top is in the same line
5.2. Do one time cleaning action, and print the test status.
5.3. If above operation still can’t solve this problem, then disassembly the printhead, cleaning the printhead manually or use cleaning machine to clean the printhead
5.4 If the status keep the same after above all operations, then check other parts or change a new printhead to test.
6. How to maintain the printer if couple of days no using the printer
If the printer won’t use more than 3 days, you must cleaning out all ink in the printhead, otherwise, the ink will be dry because the solvent volatilization, even cause irreversible damage for the nozzles of the printhead. Below is the solving methods:
6.1. Turn off the power of the printer
6.2. Move the printhead to the cleaning position, put a corrosion resistant container below the printhead for filling the waste cleaning solution
6.3. Unplug the printhead from the ink damper, then using the special cleaning solution to cleaning the printhead by glass syringe, and do this some times, at last do not suction out all cleaning solution from the printhead, put enough cleaning solution in the inner of the pritnhead, because the printhead can keep the nozzles moisture.
6.4. Please put the printhead into the clean container and seal it.
