Roland XC-540 for print cut(production stopped)
Negotiable
/ Set
1 Set(Min.Order)
- 0 per Month
- Shanghai
You May Like
- Flatbed UV Printer 9060 6090 Flatbed Printer with Ricoh Heads
- Diagraph TJ500/TJ1000 THERMAL INKJET PRINTERS
- Yaomatec Maunfacture Handheld Printer 50.8mm Expiry Date Industrial Hand Inkjet Printer
- Yaomatec Manufacture Handheld Printer 10CM Industrial Inkjet Printer Expiry Date Production Date Printer
- Yaomatec Maunfacture Handheld Printer 25.4mm Metal Wood Plastic Industrial Inkjet Printer Expiry Date printer
- Yaomatec Maunfacture Handheld Printer D30 Model English 12.7mm Logo Printer Handheld Inkjet Expiratio
Product Details
Condition: | New | Plate Type: | Other, Eco Solvent print cut printer | Place of Origin: | Japan |
Brand Name: | Roland | Model Number: | XC-540 | Usage: | Other, Interior & Exterior ads printer |
Automatic Grade: | Automatic | Voltage: | AC 110 V & 220 V | Gross Power: | 1600 W |
Dimensions(L*W*H): | 2694 [W] x 1065 [D] x 1260 [H] mm | Weight: | 197 KG | Certification: | CE |
Product Description
Specifications
Roland XC-540 for print cutPrint/cut width: 1.46 m
Color: CMYK Lc Lm
Integrated Tri-Heater System
Fast Delivery
Roland XC-540 for print cut
MODEL | XC-540 | |
Printing method / Cutting method | Piezo ink-jet/ Friction feed | |
Printing/Cutting width | 19.68 to 54 Inches/8.31 to 54 Inches | |
Acceptable media widths | 10.25 to 54 in. (260.3 to 1371.6mm) | |
Maximum media thickness | 1 mm or 40 mil | |
Maximum Media Weight | Feed Roller | 110 lb. (50 kg) |
Take-up Roller | 66 lb. (30 kg) | |
Ink cartridges | Type | Exclusive ECO-SOL MAX ink cartridges |
Capacity | Choose from 440 or 220 cc cartridges +/- 5 cc each | |
Colors | CMYKLcLm | |
Printing resolution | Maximum 1440 dpi | |
Acceptable blade tool | CAMM-1 series cutter blade | |
Print Speed | 360x360 | 441 ft2/hr |
450x360 | 293 ft2/hr | |
360x720 | 151 ft2/hr | |
720x720 | 75 ft2/hr | |
1440x1440 | 31 ft2/hr | |
Cutting speed | 11.8 in/sec | |
Blade force | 30 to 300gf | |
Blade offset compensation | 0.0 to 1.5mm | |
Distance accuracy | While the print heater is running | Error of less than ± 0.3% of distance traveled, or ± 0.3 mm, whichever is greater |
While the print heater is not running | Error of less than ± 0.3% of distance traveled, or ± 0.3 mm, whichever is greater | |
Distance accuracy (When cutting) | Error of less than +/- 0.4% of distance traveled, or +/- 0.3 mm, whichever is greater. When distance correction ([CALBRATION] -[CUTTING ADJ.]) has been preformed: error of less than +/- 0.2 % of distance preformed, or +/- 0.1mm, whichever is greater. | |
Repetition accuracy (When cutting) | + 0.1mm or less | |
Repetition between printing and cutting | + 0.5mm or less | |
Setting range for the heater temperature | Pre-heater | 86° to 122° F (30° to 50 °C) |
Print heater | 86° to 122° F (30° to 50 °C) | |
Dryer | 86° to 122° F (30° to 55 °C) | |
Interface | Ethernet (10 BASE-T / 100 BASE-TX, automatic switching) | |
Power-saving function | Automatic sleep feature (Compliant with the International ENERGY STAR Office Equipment Program) | |
Power supply | Voltage and frequency | AC 100 to 120 V +/- 10% 50/60 Hz or AC 220 to 240 V +/- 10% 50/61 Hz |
Required power capacity | 13 A (100 to 120 V) or 7 A (220 to 241V) | |
Power consumption | Printing mode | Approx. 1600W |
Sleep mode | Approx. 47W | |
Acoustic noise level | Printing mode | Approx. 64dB (A) or less (according to ISO 7779) |
Standby mode | Approx. 45dB (A) or less (according to ISO 7779) | |
Dimensions (with stand) | 106.12” [W] x 41.93” [D] x 49.62” [H] (2694 [W] x 1065 [D] x 1260 [H] mm) | |
Weight (with stand) | 338 lb. (197 kg) | |
Environment | Power on | Temperature: 59° to 90°F (15° to 32°C) 68°F (20°C) or more recommended |
Humidity: 35 to 80% (no condensation) | ||
Power off | Temperature: 41° to 104°F (5° to 40°C) | |
Humidity: 20 to 80% (no condensation) | ||
Included items | XC-540 stand, cleaning liquid cartridges, power cord, media clamps, blade, blade holder, replacement blade for sheet cutter, Roland VersaWorks Software RIP CD, cleaning kit and manuals |
