Roland Flatbed Printer LEJ-640
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Other, hybrid printer(both roll and rigid substrate)
Place of Origin:
Japan
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Roland Eco Solvent Printer XJ-540(production Stopped)NegotiableMOQ: 1 Set -
Roland Printer XJ-640(production Stopped)NegotiableMOQ: 1 Set
-
Roland Eco Solvent Printer SJ-1045EXNegotiableMOQ: 1 Set
-
Roland Printer Cutter LEC-540NegotiableMOQ: 1 Set
-
Roland Print and Cut Printer SP-540i(production Stopped)NegotiableMOQ: 1 Set
Condition
New
Plate Type
Other, hybrid printer(both roll and rigid substrate)
Place of Origin
Japan
Brand Name
Roland
Model Number
LEJ-640
Usage
Other, interior & exterior advertising printer
Automatic Grade
Automatic
Voltage
AC 100 to 240 V ± 10%, 50/60 Hz
Gross Power
500 W
Dimensions(L*W*H)
3184[W]x3658[D]x1281[H] mm
Weight
316 kg
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
roland flatbed printerColor: CMYK Lc Lm
Ink curing unit: Dual UV LED Lamp
Hybrid function; roll & sheet
fast delivery
roland flatbed printer LEJ-640
| MODEL | LEJ-640 | |
| Printing method | Piezoelectric inkjet / Grit roller feed | |
| Acceptable media | Width |
Roll media: 8.3 to 64 in. (210 to 1625 mm) Rigid or cut sheet: 9.9 to 64 in. (250 to 1625 mm) |
| Thickness |
Roll media: Maximum 39 mil (1.0 mm) with liner Rigid or cut sheet: 0.51 in. (13 mm) |
|
| Weight | Roll media: Maximum 88 lb. (40 kg) / Rigid or cut sheet: Maximum 26 lb. (12 kg) | |
| Roll outer diameter | Maximum 8.3 in. (210 mm) | |
| Core diameter | 3 in (76.2mm) | |
| 2 in (50.8mm) [requires optional flanges] | ||
| Media take-up system | Maximum 8.3 in (210 mm) outer diameter / Maximum 88 lb. (40 kg) weight | |
| Printing width | Maximum 63.6 in (1615 mm) | |
| Maximum Printing Speed | 133 sqft./hr. in CMYK mode | |
| Ink Cartridges | Type | 10.2 to 63.6 in. (259 to 1615 mm) ECO-UV inks |
| Capacity | 220 ml (± 5 ml) | |
| Colors | 6 colors (Cyan, Magenta, Yellow, Black, White and Gloss) | |
| Configuration | CMYK+Gloss+White, CMYK+White+White or CMYK+Gloss+Gloss | |
| Ink curing unit | Dual UV LED Lamps | |
| Printing resolutions | 360x720 dpi, 720x1080 dpi, 720x1440 dpi, 1440x1440 dpi | |
| Distance accuracy | Error of less than ± 0.3 % of distance traveled, or ± 0.012 in (0.3 mm), whichever is greater. | |
| Interface | Ethernet (10 BASE-T / 100 BASE-TX, automatic switching) | |
| Power-saving feature | Automatic sleep feature | |
| Power supply | Voltage & frequency | AC 100 to 240 V ± 10%, 50/60 Hz |
| Required power capacity | Maximum 5.7 A | |
| Power Consumption | During operation | Maximum 500W |
| Standby mode | Approx. 15.2 W | |
| Dimensions (with stand) |
Without table unit : 126[W]x33[D]x51[H] in (3184[W]x836[D]x1281[H] mm) With table unit: 126[W]x145[D]x51[H] in (3184[W]x3658[D]x1281[H] mm) |
|
| Weight (with stand) | Without table unit: 530 lb. (240 kg) / With table unit: 697 lb. (316 kg) | |
| Environment | Power on | Temperature: 68° to 90°F (20° to 32°C) (72°F [22°C] or more recommended) Humidity: 35 to 80% (no conde nsation) |
| Power off |
Temperature: 41° to 104°F (5° to 40°C) Humidity: 20 to 80% (no condensation) |
|
