Place of Origin Guangdong, China
Brand Name XY
Model Number XY-IR313
Type Other, Digital Camera, thermal camera surveillance
Style Mini Camera
Sensor Other, infrared IR
Technology Infrared
Special Features Waterproof / Weatherproof

High quality IR 9~32V thermal camera,thermal camera surveillance ,driving aid thermal imaging night vision camera. XY-IR313



Product Description

 XY-IR312 is  FOV: 36° X 27° size of camera: 82.8mm X 62mm X 100.5mm Lens 14.8mm 7V~36V DC



XY-IR313 is  FOV: 21° X 28° size of camera: 75mm X 58mm X 68mm Lens 19 mm 9V~32V DC

IR313 FOV smaller,but can see more clearly in the same ction is the same.

Welcome to contact us for more details and video .

Features:

The car IR aid camera's visual range is up to 5 times of the range of standard headlights.
Enables the driver to recognize pedestrians, animals and objects ahead in darkness, smoke, fog, rain and snow
Allows more time to react to any potential dangers
Convenient installation
Compact profile
Multiple application: Security and vehicle, including military vehicles and aftermarket commercial vehicles





Camera specification
Detector Type :384X288 Asi Microbolometer
Spectral Range :8~14um
Optical Lens: 19 mm /F#0.96
FOV :21° X28°
IFOV: 1.7 mrad
NETD :100mk@25℃
MRTD :500mk@25℃
Image presentation :Video Output 25HZ PAL or 30HZ NTSC
Adjust :Auto brightness and contrast adjustment

Image calibration :Auto calibration without shutter

Image recognition: auto pedestrian recognition

Alarm :auto


System performance

start up time: 8-s

Defroster

   ≤2℃ :activate defroster automatically
   @-30℃ :deice 1mm ice within 15m

   ≥7℃ :close defroster automatically
Power

   External DC adapter: 9V~32V DC
Power dissipation

   ≤3.5W

   ≤1.4W :without alarm function



Interfaces Command and Control :RS232
Image display :Real time on PC or indicated monitor Environmental

Operating Temperature :-40 deg to 70deg
Storage temperature :-45 deg to 80deg
Dust protection :MIL-std810
Rating :IP67


Physical
Weight (including lens): ≤1kg
Size: 84mm X 63mm X 101mm
