Specifications
Low temperature;Standard Accessory: Temperature printer, recrd 7 days data, 7 hour battery backup for printer
-86℃ Ultra-low Temperature Freezer Vertical Type
1.Audio and visual alarm.
2.Double Danfoss compressors with Germany EBM fan motor (only for BDF-86V348 & BDF-86V950)
3.Stainless steel inner chamber with round angel structure, easy for cleaning.
4.Double-layer door design, protecting air leakage.
5.Front door with safety lock.
Technical Parameter:
Model |
BDF-86V50 |
BDF-86V158 |
BDF-86V348 |
BDF-86V398 |
BDF-86V598 |
BDF-86V950 |
||
External Size (W*D*H)(mm) |
540*620*1115 |
700*700*1580 |
855*1006*1917.5 |
850*930*1950 |
940*950*1920 |
1500*1000*2000 |
||
Internal Size (W*D*H)(mm) |
361*429*406 |
460*455*800 |
490*607*1140 |
550*630*1140 |
700*680*1255 |
1000*700*1336 |
||
Capacity |
50L |
158L |
348L |
398L |
598L |
950L |
||
Type |
Vertical |
|||||||
Temp. Range |
-40℃~-86℃ |
-70℃~-86℃ |
-40℃~-86℃ |
|||||
Controlling Precision |
0.1℃ |
|||||||
Control System |
Microprocessor control, keyboard lock function |
|||||||
Display |
LED display |
|||||||
Alarm |
Temperature higher/lower alarm, filter inspection alarm, ambient temperature alarm |
Temperature higher/lower alarm, ambient temperature alarm, filter inspection alarm, sensor failure alarm, condense dirty&plug alarm, power failure alarm, voltage abnormal alarm, abnormal door open alarm |
Temperature higher/lower alarm, filter inspection alarm, ambient temperature alarm |
|||||
Refrigeration Type |
Direct refrigeration |
|||||||
Refrigerant |
Mixture refrigerant, composed of R134a, R404a, R23, R410A, N2, CFC free |
|||||||
Compressor |
Danfoss compressor with Germany EBM fan motor |
|||||||
1set |
1set |
2sets |
1set |
1set |
2sets |
|||
Condenser & Evaporator |
Material is cupreous |
|||||||
Construction |
Unibody design, two-times foaming technology, 100-155 mm foaming insulation, with VIP+ |
|||||||
Material |
Internal |
304 Stainless steel |
||||||
|
External |
Cold-rolled steel coated with anti-bacteria powder |
||||||
Door |
Front opening lockable door with full height handle, with vacuum release port |
|||||||
Chamber with Inner Door |
1 |
3 |
2 |
4 |
4 |
3 |
||
Shelves |
1 adjustable SS304 |
2 adjustable SS304 |
3 adjustable SS304 |
|||||
Test Port |
1, Φ18mm |
2,Φ18mm |
1, Φ18mm |
1, Φ18mm |
||||
Remote Alarm Port |
Optional |
Alarm relay parameters:DC30V, 2A |
Optional |
Optional |
||||
Caster |
4 universal casters with brake and leveling feet |
|||||||
Consumption |
450W |
630W |
1200W |
720W |
990W |
1600W |
||
Power Supply |
220V±10%; 50Hz/60Hz |
|||||||
Optional Accessory |
Chart recorder, storage racks, storage boxes. |
|||||||
Package Size (W*D*H)(mm) |
760*685*1170 |
870*860*1800 |
935*1070*2127 |
1025*1080*2170 |
1070*1030*2150 |
1350*1080*2150 |
||
Gross Weight |
95kg |
150kg |
280kg |
248kg |
318kg |
330kg |
||
